3 Components and Power Supply
Procedure
Step 1 Install the two screws (3.5x30) horizontally apart on a wall or any other vertical surface.
The screws should protrude 0.6 cm (0.25 inch) from the surface of the wall.
Warning
If you install the screws in drywall, use hollow-wall anchors (8 mm – 5/16 inch) to secure the screws. If
the screws are not properly anchored, the strain of the cables connected to the router back panel could
pull the router from the wall.
Step 2 Hang the router on the screws. This is the appropriate orientation for safe use. (See
Note
- The accessories for wall mounting the device are not provided in the package, and have to be ac-
quired separately.
- The accessories must be properly adapted to the kind of wall in place and must be chosen to ensure
that they can support the weight of the device.

3.2.4 Ceiling mounting

To attach the device Teldat 4Ge to the ceiling, use the appropriate support (not included, must be ordered separ-
ately).
Ceiling mounting support
Fig. 10:
10
Fig. 9 on page 9)
Teldat 4Ge Router
