3 Components and Power Supply
The LEDs for the Teldat 4Ge router are shown in Figure 6. The table below contains a description of them:
LEDs table
LED
LAN
PWR
W

3.2 Assembly

3.2.1 Mounting in rack

The Teldat 4Ge router cannot be mounted in a rack. However there are other types of mounting.

3.2.2 Standalone

The Teldat 4Ge router can be placed as a standalone device on a flat, stable surface.
You need to make sure that there is enough space around the router for ventilation purposes and that the electricity
cables can reach it.

3.2.3 Wall mounting

The Teldat 4Ge router can be mounted on the wall.
There are two slots on the underside of the device which are used to fix it to the wall. You can see this in section
derside Panel
We recommend the following accessories for wall mounting, valid for solid wall and Gypsum board (plaster) wall:
• 2 screws: [Coach Screw Head 90 Degrees. 3,5x30]
8
Status
Tricolor
Monochrome green
Tricolor
on page 6.
Description
Green -> connected. Blinking: con-
nection data activity
Amber -> blinking: auto-test
Red -> disconnected
Device ON/OFF. This lights up when
connected to the power source.
Off -> system stopped
Red -> interface is unavailable be-
cause it is installing, it is not enabled
(shutdown) or due to auto-test failure
Yellow -> idle
• Rapid blinking. It has not registered
in the network or the quality is in-
sufficient.
• Slow blinking. GSM connection
(GPRS).
• Steady. WCDMA (UMTS/HSDPA)
connection.
Green -> connected. Blinking: con-
nection data activity.
Teldat S.A.
Un-
Teldat 4Ge Router
