Chapter 3 Components and Power Supply

The following chapter provides detailed information on the chassis of the Teldat 4Ge router and its components. This
information includes:

• Components.

• Information on assembly.
• Power supply.
• RESET button.
• Data connection.
• SIM card installation.
3.1 Components

3.1.1 Front Panel

The following figure shows the front panel. Here you can see the slot to insert the SIM card and one of the WWAN
antenna connectors.
Front Panel
Fig. 1:
The front panel elements are as follows:
Front panel elements table
Item
A
B

3.1.2 Rear Panel

The following figure shows the rear panel. Here you can see all the connectors for the Teldat 4Ge router.
Teldat 4Ge Router
Description
WWAN antenna for the Teldat 4Ge.
Slot for the SIM card.
