F C
OLLOW THE ONTOUR
Follow the Contour allows you to navigate a contour on the Chart View. When you start i-Pilot Link navigation to Follow the Contour,
all other types of navigation are stopped on the HELIX control head and the Ethernet network. AutoChart Live also allows you to follow
depth contours, weed edges, and bottom hardness using the i-Pilot Link.
WARNING! Watch for a turning propeller and be prepared for boat movement when working with Follow the Contour. If Prop Auto
On is turned on, the propeller will automatically turn on when Follow the Contour is engaged, even if the engagement is accidental.
A turning propeller can cause injury.
NOTE: When the i-Pilot Link is following the contour, the Current Track is not saved, and iTracks cannot be recorded.
1
Preparation
Use the following instructions to prepare the control head to Follow the Contour.

Install the Map Card

To use Follow the Contour, an i-Pilot compatible map card must be installed and selected as the map source. If using an AutoChartPC
Live Data connection, confirm the connection between your PC and HELIX control head.
Required: i-Pilot Compatible Humminbird LakeMaster Map Card, LakeMaster PLUS Map Card, AutoChart ZeroLine Map Card, or
AutoChart Live saved map.
1. Install a compatible map card.
See your control head operations guide for installation details.
2. If the control head does not select the map source automatically, select the Main Menu > Chart tab > Map Source.
Select the installation location of the map card.
WARNING! Do not leave the SD slot cover open. The slot cover should always be closed to prevent water damage to the unit.

Set the Contour Lines to Visible

1. Main Menu: Press the MENU key twice. Select the HB Chart tab.
2. Select Contour Lines.
3. Select Visible.
