A P
-
DJUST i ILOT
Use the instructions in this section to adjust i-Pilot Link alarms. When an alarm is turned on, an alert will sound and/or display on
the control head to indicate the threshold has been met or exceeded. For more information about alarms or to set additional alarms,
see the HELIX Operations Manual.
NOTE: When i-Pilot Navigation is turned on in the menu system, the Arrival Alarm in the Alarms tab is replaced by the i-Pilot
Pre-Arrival Alarm, and the Off Course (XTE) Alarm is replaced by the i-Pilot Off Course (XTE) Alarm.

Adjust the i-Pilot Pre-Arrival Alarm

The i-Pilot Pre-Arrival Alarm provides an alert when the boat is within the set distance to the destination point in a waypoint, route,
or iTrack. For example, if i-Pilot Link is navigating an iTrack, and the Pre-Arrival Alarm is set to 100 feet, the alert will trigger when
the boat is within 100 feet from the iTrack End Point.
CAUTION! When the alert sounds, the i-Pilot Link will soon transition to the type of navigation set in the Arrival Mode menu option.
Be prepared that you may need to take manual control of the boat. See Configure i-PIlot Link with the Control Head: Set the
Arrival Mode.
1. Main Menu: Press the MENU key twice. Select the Accessories tab.
2. Select i-Pilot Settings. Press the RIGHT Cursor key.
3. Select i-Pilot Pre-Arrival Alarm.
4. Press the RIGHT or LEFT Cursor keys to adjust the alarm threshold.
L A
INK LARMS
i-Pilot Link navigation in progress
Arrival Circle
arrival circle
boat icon
