Start Circle Mode at the Cursor Position

The boat must be within 1/4 mile of the cursor position to begin Circle Mode navigation.
1. Use the Cursor Control key to move the cursor to a position on the chart.
2. Press the GO TO key.
3. Select Circle > At Cursor. Press the RIGHT Cursor key.
Adjust the Radius (optional): Select Radius. Press the RIGHT or LEFT Cursor keys to adjust the setting.
4. Select Clockwise or Counterclockwise. Press the RIGHT Cursor key.
CAUTION! Be prepared for boat movement as the prop will automatically be enabled and the prop speed will automatically adjust
to move the boat when Circle Mode is engaged. If the boat does not move, confirm the prop is turned on in the menu system (see
Propeller Controls).
Starting Circle Mode at the Cursor Position
boat icon (stationary) cursor with Circle Mode preview
Move the Cursor
Open the GO TO
Menu
selected
direction
circle radius
setting
