Label
Name
Bearing
Bearing
Course Over Ground
COG
(Course)
Distance to Go
DTG
(Distance)
Estimated Time
ETA
of Arrival
Position (#)
GPS
Speed
Speed
Triplog
Triplog
TTG
Time to Go
XTE
Cross Track Error
Customize Digital Readouts
If you have Digital Readouts set to Boxes, you can select the data that will be displayed in each box. Use the Select Readouts menu
to set your standard digital readouts. Use the Select Nav Readouts menu to set the digital readouts that will be displayed during
navigation.
1. Main Menu (Advanced User Mode): Press the MENU key twice. Select the Setup tab.
2. Choose Select Readouts or Select Nav Readouts. Press the RIGHT Cursor key.
3. Select a readout window (Readout 1, 2, 3, etc.).
4. Select a digital readout.
Hide: To hide a readout window, select Off.
Description
The direction to a destination waypoint measured in degrees from north.
The direction the boat is traveling measured in degrees from North. When the COG is equal
to Bearing, the boat is said to be on course and will arrive at the destination in the most
efficient manner.
The distance between the boat position and the next waypoint on the route.
The estimated time of arrival to the next waypoint on the route.
The latitude and longitude coordinates of the boat position based on the GPS receiver
installation location.
Speed is the measurement of the boat's progress across a given distance based on the
speed measurement provided by the GPS.
The elapsed time since the triplog was last reset, the distance traveled since last reset, and
the average speed during timed interval. To reset the triplog, select the Main Menu > Settings
tab > Triplog Reset.
The estimated time required to reach the next waypoint on the route. TTG is calculated using
the SOG (Speed Over Ground) and DTG (Distance to Go).
The straight-line distance of the boat from the intended route. XTE measures how far the
boat is off course.
