Set the Water Level Offset

When you start your trip for the day, it is important to note if the water level is higher or lower than normal. For example, if the lake
is down 5 feet, set the Water Level Offset setting to -5. The displayed numbers on the Contour Lines will adjust from the Water
Level Offset setting, and the water level offset will be highlighted in brown to extend the land visually on the display.
NOTE: A Humminbird LakeMaster map card must be installed and selected as the map source to enable these features.
1. Main Menu: Press the EXIT key twice to return to the main menu. Select the HB Chart tab.
OR
Press the MENU key twice. Select the HB Chart tab.
2. Select Water Level Offset.
3. Press the RIGHT or LEFT Cursor keys to adjust the setting.
If the water level is higher than normal, set a (+) positive amount.
If the water level is lower than normal, set a (-) negative amount.
If the water level has not changed (normal), set Water Level Offset to (0) zero.

Water Level Offset (Set to 0 = Off)

NOTE: For additional LakeMaster map card menus, see Display Humminbird LakeMaster Contour Lines and Depth Ranges in this
manual. For additional features related to your LakeMaster map card, visit our Web site to download the accessory guide.

Water Level Offset Adjusted to -4

If the water is lower than normal, set the Water Level Offset to a negative
number, and the land will extend visually on the map (as shown above). If the
water is higher than normal, set the Water Level Offset to a (+) positive amount,
and the water line will extend visually on the map.
