5 - 74 BRAKES
SPECIFICATIONS

TONE WHEEL RUNOUT

FRONT TONE WHEEL:
Maximum Runout . . . . . . . . . 0.15 mm (0.006 in.)
REAR TONE WHEEL:
Maximum Runout . . . . . . . . . 0.15 mm (0.006 in.)
WHEEL SPEED SENSOR-TO-TONE WHEEL
CLEARANCE
FRONT WHEEL:
Minimum Clearance . . . . . . . 0.42 mm (0.017 in.)
Maximum Clearance . . . . . . . 1.71 mm (0.067 in.)
REAR WHEEL:
Minimum Clearance . . . . . . . 0.38 mm (0.015 in.)
Maximum Clearance . . . . . . . 1.31 mm (0.052 in.)

WHEEL SPEED SENSOR RESISTANCE

FRONT AND REAR:
Allowable Resistance . . . . . . . . . 900 - 1300 ohms
BRAKE FASTENER TORQUE SPECIFICATIONS
DESCRIPTION
BRAKE TUBES:
Tube Nuts . . . . . . . . . . . . . . 17 N·m (145 in. lbs.)
ABS INTEGRATED CONTROL UNIT (ICU):
Mounting Bracket Bolts . . . . 11 N·m (97 in. lbs.)
CAB To HCU Screws . . . . . . . . 2 N·m (17 in. lbs.)
LH
TORQUE
