Power cord criteria

AC power connections

You must use a power cord set that meets the following criteria:
Rating: In the U.S. and Canada, cords must be UL (Underwriters Laboratories,
■
Inc.) Listed/CSA (Canadian Standards Organization) Certified type SJT, 18-3
AWG (American Wire Gauge). Outside of the U.S. and Canada, cords must be
flexible harmonized (<HAR>) or VDE (Verband Deutscher Electrotechniker,
German Institute of Electrical Engineers) certified cord with 3 x 0.75-mm
conductors rated 250 VAC (Volts Alternating Current
Connector, wall outlet end: Cords must be terminated in a grounding-type male
■
plug that is designed for use in your region. The connector must have the
certification marks that show a certification by an agency that is acceptable in
your region. For U.S. the connector must be listed and rated 125% of the overall
current rating of the appliance.
Connector, appliance end: The connectors that plug into the AC receptacle on
■
the appliance must be an approved IEC (International Electrotechnical
Commission) 320, sheet C13, type female connector.
Cord length and flexibility: Cords must be less than 4.5 meters (14.76 feet) long.
■
See "Appliance shutdown and hardware access warnings "
NetBackup appliances and storage shelves currently ship with two AC power cords.
To improve the power distribution within a rack environment, Symantec will ship
two Power Distribution Unit (PDU) compatible cords (C13-C14) instead of the AC
power cords with these devices. The transition to the new cords will be gradual.
These cords connect the appliance and the storage shelf to AC power outlets on
the PDU in the equipment rack. Each cord includes a standard IEC-60320-C14
plug and an IEC-60320-C13 connector.
Figure 5-1 and Table 5-1
C13 connector to the appliance or to the storage shelf
Figure 5-1
Detailed safety and maintenance information
show the C13 connector.
Power cord criteria
on page 53.
