LED status indicators

This chapter includes the following topics:
■
■
■
■
■
■
■

Appliance disk drive LEDs

Drive bay slots are labeled 0-11 starting from the lower, left corner. Each drive has
two LEDs which appear as follows:
Figure 2-1
Appliance disk drive LEDs
Appliance front panel LEDs
Appliance Ethernet port LEDs
8Gb FC HBA LEDs
10GE add-in card LEDs
Symantec Storage Shelf disk drive module and system LEDs
Symantec Storage Shelf I/O module and power module LEDs
Appliance disk drive LEDs
Chapter
2
