Appliance front panel LEDs

Disk drive module LEDs
Table 2-1
Number
1
2
See "Appliance front panel LEDs"
Front panel LEDs
Figure 2-2
LED functions and indicators
Table 2-2
Number Description
1 System ID button with integrated LED.
2 Hard drive activity LED
3 ID button with integrated LED
Description Color
Status LED Not lit
Solid amber
Blinking amber
Activity LED Not lit
Solid green
Blinking green
Blinking green
occasionally
on page 17.
LED status indicators
Appliance front panel LEDs
Indication
No faults
Disk fault
RAID rebuild is in
progress
The disk has spun
down.
No disk activity.
The disk spins up.
Commands are
processed.
17
