I/O module and power module descriptions (continued)
Table 2-8
Number Component
5 I/O module LED
6 Power module LED
Note: When you start the Symantec Storage Shelf, the primary I/O module (on the
left side of the rear panel) starts up first. The LED turns green a few seconds after
the main startup. The LED of the secondary I/O module (on the right of the rear
panel) starts after the primary module is operational.
Symantec Storage Shelf I/O module and power module LEDs
LED states
Solid green
■
Flashes green
■
Red
■
Not lit
■
Solid green
Flashes green
Red
Not lit
LED status indicators
Description
Ready
■
n/a
■
Starting up
■
Off
■
Power ok
Power ok, but turned off
Turning on the power failed
Power not detected
