Chapter 4 - Hardware Description
4-6
Figure 4-5 shows the top view of the inside of the MGC-100. The Main
Control Module, Functional Modules, and I/O cards are all connected to the
Backplane. The Power Supply Modules, located underneath the Main Control
Module and the Functional Modules, are connected to the Powerplane.
Backplane
Main Control
Module
Figure 4-5: MGC-100 top (internal) view
REAR
I/O cards
Function modules
FRONT
