Chapter 5 - System Maintenance
5-6
The three Functional Module LEDs function as a group. Each state of the
Functional Module and its associated LED array is described in Table 5-2.
The (IDLE, ACTIVE, FAILURE, and PARTIAL FAILURE) states are the
operational modes of the Functional Module. The (RESET, WAITING FOR
MCMS and LOADING SOFTWARE) indicates the stages during the startup
procedure of the Functional Module.
Figure 5-2: Function Module LEDs
Module State
IDLE—Ready, but not used in a
conference
ACTIVE—Used in one or more
conferences
FAILURE—Error state; board is
out of operation
PARTIAL FAILURE—Error state;
part of board is out of operation
RESET—Board is in Reset state
TEST—Power-on self test
WAITING FOR MCMS—Waiting
for MCMS to start loading software
LOADING SOFTWARE
STBY FAIL
ON OFF
ON OFF
OFF ON
ON Flashing
ON ON
OFF OFF
Flashing Flashing
ON Flashing
ACTIVE
OFF
ON
OFF
ON/OFF
ON
Flashing
OFF
OFF
