Main
Control
Module
CONT
Critical
POLYCOM
Major
Minor MGC-50
L0
Power
L1
L2
L3
PWR
OUT
Floppy Disk Drive
COM Port
Figure 5-2: MGC-50 front panel

LED Indicators

The following LEDs appear on the front panel:
8 LEDs on the Main Control Module
•
3 LEDs on each Functional Module except for the Network Interface
•
Module which contains additional LED for each PRI span connected to
the system
2 LEDs for each of the MGC-100 Power Supply modules
•
1 LED on the MGC-50 Power Supply
•
MGC Hardware and Installation Manual
Functional Modules
Ejectors
LEDs
PRI-8 MG-323 AUDIO AUDIO VIDEO VIDEO VIDEO
Stby Stby Stby Stby Stby Stby Stby
Fail Fail Fail Fail Fail Fail Fail
Active Active Active Active Active Active Active
Line 1
Line 2
Line 3
Line 4
Line 5
Line 6
Line 7
Line 8
VIDEO
Stby
Fail
Active
