Chapter 1 - Before You Begin
Scope of Manual
1-8
This manual describes the MGC-50 and the MGC-100 hardware and
installation procedure. It is intended for service engineers, system
administrators and system operators who need to install, configure and
maintain the MGC unit.
Detailed information on using the system, including starting and shutting
down the system, is provided in the MGC Manager User's Guide.
This manual assumes the user has the following knowledge:
Familiarity with the Windows 95®, Windows 98®, Windows 2000®,
•
Windows NT®, and Windows XP® environment and interface
Basic knowledge of videoconferencing concepts and terminology
•
The MGC Hardware and Installation Manual includes the following topics:
Chapter 1 - Before You Begin
•
Provides a general description of the MGC unit, its main features and
description of the MGC Hardware and Installation Guide.
Chapter 2 - MGC Unit Hardware Installation
•
Installing the MGC unit and connecting it to the operator workstations.
Chapter 3 - System Architecture
•
Describes the system architecture and the data flow.
Chapter 4 - Hardware Description
•
Describes the various components that make up the MGC unit.
Chapter 5 - Maintenance
•
Describes the controls and LED indicators and provides maintenance
procedures.
•
Appendix A - Interfaces Pin Assignment
Describes the pinout of the various MGC unit connectors.
