Connecting And Setting Up The Mgc-50; Mgc-50 Dongle - Polycom DOC2237A Hardware Installation Manual

Chapter 2 - Hardware Installation

Connecting and Setting Up the MGC-50

2-26
Use the MGC-50 rear panel diagram below for reference.
COM 1
Fuse
Main Switch
AC Inlet
Figure 2-13: MGC-50 Rear Panel with External Connectors
To connect the MGC-50 to the network and power source and set up the
system the following procedures are performed:
Connecting the MGC unit to the power source (AC inlet)
•
Connecting the MGC unit to the LAN Network
•
Connecting the MGC unit to the Operator Workstation (PC) directly via
•
RS-232 (optional)
Connecting the MGC unit to the network(s)
•

MGC-50 Dongle

MGC-50 is shipped with a serial dongle installed on COM1 on the MCU rear
panel. The dongle is required for normal operation of the MCU. If the dongle
is missing, please contact support.
Main Control
Module Cover
IO Card
LAN
Fan
RJ45
Connector
