Chapter 5 - System Maintenance
5-8
Fuse
Main Switch
AC Inlet
Figure 5-4: MGC-50 rear panel controls
The main power switch is used during installation, and replacement of fans,
main control module and power supply since the functional modules are hot
swappable. The switch includes an AC fuse.
Slot A
IO Card
COM 1
LAN
RJ45
Connector
Main Control
Module Cover
Fan
