Point Types,

GENMON

SGENMON

FPUMP

SFPUMP

S2STAGE

Technical Manuals Online! - http://www.tech-man.com
Continued
Used when emergency generator monitoring is required. The shorted condition
of the circuit indicates an abnormal status and is indicated by the Supervisory
Service LED. The current limited condition of the circuit indicates that the
generator is running, and can be tracked with an LED (must be programmed). A
current limiting resistor must be installed for this to happen.
Circuit Status
Normal
Limited
Open
Short
Same operation as the GENMON point type, but the generator running condition
automatically displays and requires operator acknowledgment.
Circuit Status
Normal
Limited
Open
Short
Used to monitor fire pump conditions. The shorted condition indicates that the
fire pump is abnormal A current limited condition indicates that the fire pump is
running.
Circuit Status
Normal
Limited
Open
Short
Same as the FPUMP point type, except that the fire pump running condition
requires operator acknowledgement.
Circuit Status
Normal
Limited
Open
Short
Used for 2-stage alarms. The current limited operation of any device indicate a
Stage 1 Alarm. A short on the point's circuit, such as a key switch operation,
causes a Stage 2 Alarm.
Circuit Status
Normal
Limited
Open
Short
LCD Text
Generator Monitor
Generator Monitor
Generator Monitor
LCD Text
Generator Monitor
Generator Monitor
Generator Monitor
LCD Text
Fire Pump Monitor
Fire Pump Monitor
Fire Pump Monitor
LCD Text
Fire Pump Monitor
Fire Pump Monitor
Fire Pump Monitor
LCD Text
2 Stage Monitor
2 Stage Monitor
2 Stage Monitor
A-13
Status
Normal
Running
Open Trouble
Abnormal
Status
Normal
Running
Open Trouble
Abnormal
Status
Normal
Running
Open Trouble
Abnormal
Status
Normal
Running
Open Trouble
Abnormal
Status
Normal
Stage 1 Alarm
Open Trouble
Stage 2 Alarm
