Signal; Ssignal; Suprel; Supv - Simplex 4010 Applications Manual

Point Types,

SIGNAL

SSIGNAL

SUPREL

SUPV

Technical Manuals Online! - http://www.tech-man.com
Continued
Generic Alarm Signal – no default operation. Used for selective control
(Custom Control) of audible or visible notification appliances. Points assigned
with this point type operate on general alarm.
Circuit Status
ON
OFF
Disable TBL
OFF AUTO TBLE
Alarm signal – On until Silence. Used for any signaling device (such as an
audible or visible notification appliance) that is required to be on until reset.
Points assigned with this type operate on general alarm (that is, when any point
within L1 General Alarm List goes into alarm). Points with this type turn OFF
when an Alarm Silence is performed.
Circuit Status
Normal
Normal
Disable TBL
OFF AUTO TBLE
Suppression release (agent discharge) output.
Circuit Status
Normal
Normal
Disable TBL
Sprinkler supervisory signal. Turns ON when any point in L3 Sprinkler
Supervisory Monitor Points activates. Turns OFF on ACK or when the
supervisory clears. Example: Have a relay and its point type is SUPV, used to
set off a bell when a tamper is triggered or a gate valve is opened.
Circuit Status
Normal
Normal
Disable TBL
LCD Display
Signal Circuit
Signal Circuit
Signal Circuit
Signal Circuit
Signal Circuit
LCD Display
Signal Circuit
Signal Circuit
Signal Circuit
Signal Circuit
Signal Circuit
LCD Display
Signal Circuit
Signal Circuit
Signal Circuit
Signal Circuit
LCD Display
Signal Circuit
Signal Circuit
Signal Circuit
Signal Circuit
A-8
System Status
ON
OFF
CODING
TROUBLE
TROUBLE
System Status
ON
OFF
CODING
TROUBLE
TROUBLE
System Status
ON
OFF
CODING
TROUBLE
System Status LED
ON
OFF
CODING
TROUBLE
Continued on next page
