Svisual; Swater; Tsignal - Simplex 4010 Applications Manual

Point Types,

SVISUAL

SWATER

TSIGNAL

Technical Manuals Online! - http://www.tech-man.com
Continued
Visual – on until silence. Points assigned with this point type are ON when any
point within L1, General Alarm List, goes into alarm. Visual Notification
Appliances assigned this point type remain ON until an Alarm Silence is
performed.
Circuit Status
Normal
Normal
Disable TBL
OFF AUTO TBL
Waterflow signal – on until silence. Points with this point type turn ON when
any point in L2, Waterflow Alarm Monitor List, goes into alarm. Points remain
activated until the Alarm Silence.
Circuit Status
ON
OFF
Disable TBL
Disable TBL
Trouble/Supervisory Signal On until Clear. Points with this point type turn ON
when any trouble or supervisory condition occurs. Points turn OFF when the
trouble or supervisory condition is cleared.
Circuit Status
ON
ON
Disable TBL
Disable TBL
LCD Display
Visual
Visual
Visual
Visual
Visual
LCD Display
Signal Circuit
Signal Circuit
Signal Circuit
Signal Circuit
Signal Circuit
LCD Display
Signal Circuit
Signal Circuit
Signal Circuit
Signal Circuit
Signal Circuit
A-9
System Status
ON
OFF
CODING
TROUBLE
TROUBLE
System Status
ON
OFF
CODING
TROUBLE
TROUBLE
System Status
ON
OFF
CODING
TROUBLE
TROUBLE
Continued on next page
