1.1 System function
1.1.1. Self‐diagnosis
Diagnose CPU, memory, LCD, I/O interface, parameter state, coordinates and processing program
comprehensively every time the system is started or reset; diagnose power supply, principal axis, limit and I/O
ports in real‐time during operating.
1.1.2. Compensation
Automatic reverse clearance compensation
Automatic tool length compensation
Automatic tool radius compensation
Automatic tool radius biasing and automatic tool tip transition
1.1.3. Abundant instruction system
Scaling instruction
Mirror processing instruction
Tool biasing instructions
Program cycle, program skip, program shift, program transfer, different end processing modes, macro
definition and program management instructions
Fixed‐point instructions: starting point, setting point, etc.
Linear, arc and spiral interpolation instructions
Six workpiece coordinate systems, nine extension coordinate systems and one reference point
1.1.4. Full Chinese menu operation & full screen edit
DK system uses cascading menu structure and full Chinese operation to ensure simple operation and
visibility.
1.1.5. Abundant error‐correction functions
Point out the nature and correct the errors in operation.
1
BZ001M056A ADT‐DK300A/400A Engraving Machine
1. Overview
