067
Pressure Signal ELevel
068
ChuckSignal ELevel
Range
Unit
Authority
Default
Effective time
Note
069
OilPressure Open(min)
070
OilPressure Keep(sec)
071
OilPressureOut Freq(Hz)
072 OilInspect ELevel
Range
Unit
Authority
Default
Effective time
Note
BZ001M056A ADT‐DK300A/400A Engraving Machine
electric cabinet door and similar sensitive occasions. If there are several
insecure places, please connect the signals in parallel to safety signal
test pin of the system.
Considering the convenience of maintenance, safety signals are checked
only when the system starts processing, and won't prompt in idle state.
: 0~1
: LOGIC VOLTAGE LEVEL
: Operation admin or higher
: 0
: Instant
: Set the effective voltage level of system air pressure alarm; set the
effective voltage level of system chuck alarm.
Both air pressure alarm and emergency stop alarm are effective
globally; the detection ports of air pressure alarm and chuck alarm are
set in port parameters.
: 0~ 10000 1~10000 0~100 0,~ 1
: Min Sec Hz LOGIC VOLTAGE LEVEL
: Operation admin or higher
: 0, 1, 0, 0
: Instant
: Set the system lubricating function.
Oil pressure timing open parameter controls the lubrication timing
function, 0 is to turn off the lubrication, non‐zero is to turn on the
lubrication port after the time specified by timing parameters (min); the
oil pressure hold time sets the hold time of output lubrication port
(unit: second), oil control frequency is to control the lubrication signal
output mode, 0 is the jog mode, non‐zero is the time to control the
96
