2.1 LCD/keypad
Caution:
Press the submenu buttons to perform the operations of submenus.
Manual axis moving and edit & input are composite. It has different definitions according to the modes.
System working mode switch section is used to switch working modes, which can improve the security
and system performance. Handwheel and single step mode are switched with Repeat button.
3
BZ001M056A ADT‐DK300A/400A Engraving Machine
2. Operating panel
Fig. 3.1 DK300A Operating Panel Diagram
