Table A.8: Mini Pcie1: Mini Pcie - Advantech UTC-315 POS Series User Manual

Table A.8: Mini PCIe1: Mini PCIe

Part Number 1654002538
Footprint FOX_AS0B226-S68K7F
Description Mini PCIe 52 P 6.8 mm 90 D SMD AS0B226-S68Q-7H
Pin Pin Name
1 MPCIe1_Wake#
2 +3.3VSB
3 NC
4 GND
5 NC
6 NC
7 MPCIe_CLKREQ#
8 NC
9 GND
10 NC
11 CLK_Mini_PCIe-
12 NC
13 CLK_Mini_PCI+
14 NC
15 GND
16 NC
17 NC
18 GND
19 NC
20 MPCIe1_Disable#
21 GND
22 PLTRST#
23 PCIE_RX-
24 +3.3VSB
25 PCIE_RX+
26 GND
27 GND
28 +1.5V
29 GND
30 SMB_CLK_MPCIe1
31 PCIE_TX-
32 SMB_DAT_MPCIe1
33 PCIE_TX+
34 GND
35 GND
36 USB_D-
37 GND
38 USB_D+
39 +3.3VSB
40 GND
41 +3.3VSB
42 NC
