A.1 Pin Assignments

Table A.1: CN1: Backlight

Part Number
Footprint
Description
Pin
1
2
3
4
5
6
7
8
Table A.2: CN2: Internal USB
Part Number
Footprint
Description
Pin
1
2
3
4
5
UTC-315 POS Series User Manual
1655004512-01
WF_8P_49_BOX_D
Wafer Box 8 P 1.25 mm 180 D(M) DIP A1251WV0-8P
Pin Name
+12V_Inverter
+12V_Inverter
GND
GND
BKLT_EN
Bright1
+12V_Inverter
GND
1655000453
WHL5V-2M-24W1140
Wafer Box 2.0 mm 5 P 180 D(M) DIP WO/Pb JIH VEI
Pin Name
+5V
D-
D+
GND
GND
30
