Table A.9: MINI PCIE1: Mini PCIe

Part Number 1654002538
Footprint FOX_AS0B226-S68K7F
Description Mini PCIe 52P 6.8 mm 90D SMD AS0B226-S68Q-7H
Pin Pin Name
1 MPCIE1_WAKE#
2 +3.3 VSB
3 NC
4 GND
5 NC
6 NC
7 MPCIE_CLKREQ#
8 NC
9 GND
10 NC
11 CLK_MINI_PCIE-
12 NC
13 CLK_MINI_PCI+
14 NC
15 GND
16 NC
17 NC
18 GND
19 NC
20 MPCIE1_DISABLE#
21 GND
22 PLTRST#
23 PCIE_RX-
24 +3.3 VSB
25 PCIE_RX+
26 GND
27 GND
28 +1.5 V
29 GND
30 SMB_CLK_MPCIE1
31 PCIE_TX-
32 SMB_DAT_MPCIE1
33 PCIE_TX+
34 GND
35 GND
36 USB_D-
37 GND
38 USB_D+
39 +3.3 VSB
40 GND
41 +3.3 VSB
42 NC
