- Page 1 Quick Start Guide UTK-7000 Assembly Instructions, UTK- 7000-Desktop UTK-7000-Tower...
-
Page 2: Product Warranty (2 Years)
No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. The information provided in this manual is intended to be accurate and reliable. -
Page 3: Technical Support And Assistance
Technical Support and Assistance Visit the Advantech website at www.advantech.com/support to obtain the latest product information. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before calling: –... -
Page 4: Safety Instructions
In accordance with IEC 704-1:1982 specifications, the sound pressure level at the operator’s position does not exceed 70 dB (A). DISCLAIMER: These instructions are provided according to IEC 704-1 standards. Advantech disclaims all responsibility for the accuracy of any statements contained herein. UTK-7000 Quick Start Guide... -
Page 5: Safety Precautions - Static Electricity
Do not touch any components on the CPU card or other cards while the PC is powered on. Disconnect the power before making any configuration changes. A sudden rush of power after connecting a jumper or installing a card may damage sensitive electronic components. UTK-7000 Quick Start Guide... - Page 6 UTK-7000 Quick Start Guide...
-
Page 7: Table Of Contents
Table 1.6: URP TP808 Printer Door Assembly Instructions ..11 USC\UTC All-In-One Series Assembly Instructions........ 12 Table 1.7: .................. 12 Table 1.8: .................. 13 Epson TM88VI Printer Removal Instructions .......... 13 URP TP805 Printer Removal Instructions..........14 1.10 URP TP808 Printer Removal Instructions..........15 UTK-7000 Quick Start Guide... - Page 8 UTK-7000 Quick Start Guide viii...
-
Page 9: Chapter 1 Assembly Instructions
Chapter Assembly Instructions... -
Page 10: Desktop Assembly Instructions
Attach desktop to bottom plate using 4 screws (M6*8L) from PE bag. Table 1.1: Desktop Assembly Instructions Item Part Number Description 19Z0002911N001 bottom Plate U for UTK-7000 Powder 19Z0002914N001 Printer Case U for UTK-7000 Powder 1960114990N000 wire saddle Bracket for UTK-7000 UTK-7000 Quick Start Guide... -
Page 11: Tower Assembly Instructions
Attach Tower to desktop using 4 screws (M6*8L) from PE bag. Table 1.2: Tower Assembly Instructions Item Part Number Description 19Z0002911N001 bottom Plate U for UTK-7000 Powder 19Z0002914N001 Printer Case U for UTK-7000 Powder 1960114990N000 wire saddle Bracket for UTK-7000 19Z0002913N001... -
Page 12: Epson Tm88Vi Printer Assembly Instructions
Note! The product has a reserved hole, which can be fixed on the table or floor with M8*20 screws. 1.3 Epson TM88VI Printer Assembly Instructions Attach the adapter to the Velcro tape. UTK-7000 Quick Start Guide... - Page 13 First, Route needed cables from USC\UTC Series through desktop (Refer to page 13), and then the wire-saddle is locked with 4 screws (M3*6L). Attach printer to EPSON TM88VI bracket using 4 screws (T3*8L). UTK-7000 Quick Start Guide...
-
Page 14: Urp Tp805 Printer Assembly Instructions
Table 1.3: Epson TM88VI Printer Assembly Instructions Item Part Number Description 1960114995N000 TM-T88V Bracket for UTK-7000 1935230800 Screw T3x8L R/S D=5.5 H=2 (2+) ST Ni 1931030620 Screw M3*6L S/S D=6 H=1.5 + ST BLK 1.4 URP TP805 Printer Assembly Instructions Attach the adapter to the Velcro tape. - Page 15 First, Route needed cables from USC\UTC Series through desktop. (Refer to page 13), and then the wire-saddle is locked with 4 screws (M3*6L) Attach TP805 printer to TP805 bracket using 4 screws (T3*8L). UTK-7000 Quick Start Guide...
-
Page 16: Urp Tp808 Printer Assembly Instructions
Table 1.4: URP TP805 Printer Assembly Instructions Item Part Number Description 1960114996N000 TP805 Bracket for UTK-7000 1935230800 Screw T3x8L R/S D=5.5 H=2 (2+) ST Ni 1931030620 Screw M3*6L S/S D=6 H=1.5 + ST BLK 1.5 URP TP808 Printer Assembly Instructions Attach the adapter to the Velcro tape. - Page 17 First, Route needed cables from USC\UTC Series through desktop (Refer to page 13), and then the wire-saddle is locked with 4 screws (M3*6L). Attach TP808 printer to TP808 bracket using 2 screws (T3*8L). UTK-7000 Quick Start Guide...
- Page 18 Attach Top cover to desktop using 2 screws (M3*6L). Table 1.5: URP TP808 Printer Assembly Instructions Item Part Number Description 1960114993N001 TP808 Bottom Bracket for UTK-7000 Powder 1960114994N001 TP808 top Cover for UTK-7000 Powder 1935230800 Screw T3x8L R/S D=5.5 H=2 (2+) ST Ni 1931030620 Screw M3*6L S/S D=6 H=1.5 + ST BLK...
-
Page 19: Urp Tp808 Printer Door Assembly Instructions
Plate U for UTK-7000 Powder 19Z0002914N001 Printer Case U for UTK-7000 Powder 1960114990N000 wire saddle Bracket for UTK-7000 19Z0002915N001 Printer door Cover U for UTK-7000 Powder 1931030620 Screw M3*6L S/S D=6 H=1.5 + ST BLK UTK-7000 Quick Start Guide... -
Page 20: Usc\Utc All-In-One Series Assembly Instructions
UTC or USC Series. Assemble AIO to top slotted holes on stand bracket. Install desktop cables according to the diagram. Table 1.7: Item Part Number Description 1930001101 Screw M4x6L 1/4R/S D=9.2 H=2.5 (2+) ST Ni NK 4 UTK-7000 Quick Start Guide... -
Page 21: Epson Tm88Vi Printer Removal Instructions
Install tower cables according to the diagram. Table 1.8: Item Part Number Description 1930001101 Screw M4x6L 1/4R/S D=9.2 H=2.5 (2+) ST Ni NK 4 1.8 Epson TM88VI Printer Removal Instructions Remove 2 screws and then remove the printer (M3*6L). UTK-7000 Quick Start Guide... -
Page 22: Urp Tp805 Printer Removal Instructions
Remove 4 screws (M3*6L), then remove the wire-saddle. Remove the printer cable and printer adapter. 1.9 URP TP805 Printer Removal Instructions Remove 2 screws and then remove the printer (M3*6L). UTK-7000 Quick Start Guide... -
Page 23: Urp Tp808 Printer Removal Instructions
Remove 4 screws (M3*6L), then remove the wire-saddle. Remove the printer cable and printer adapter. 1.10 URP TP808 Printer Removal Instructions Remove 2 screws (M3*6L), then remove the top cover. UTK-7000 Quick Start Guide... - Page 24 Push the printer up and remove it from the wire-saddle. Remove 4 screws (M3*6L), then remove the wire-saddle. Remove the printer cable and printer adapter. UTK-7000 Quick Start Guide...
- Page 25 UTK-7000 Quick Start Guide...
- Page 26 No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopying, recording, or otherwise, without prior written permission from the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2024...
