Chapter 1 Introduction

1-1. ABOUT THIS MANUAL

Thank you for purchasing our PSB-701LF Intel® Core 2 Duo/ Core 2
Quad Full Size CPU Card enhanced with VGA/Sound/2LAN, which is
fully PC / AT compatible. The PSB-701LF provides faster processing
speed, greater expandability and can handle more tasks than before. This
manual is designed to assist you how to install and set up the system. It
contains four chapters. The user can apply this manual for configuration
according to the following chapters:
Chapter 1 Introduction
This chapter introduces you to the background of this manual, and the
specifications for this system. The final page of this chapter will indicate
how to avoid damaging this board.
Chapter 2 Hardware Configuration
This chapter outlines the component locations and their functions. In the
end of this chapter, you will learn how to set jumper and how to configure
this card to meet your own needs.
Chapter 3 Software Utilities
This chapter contains helpful information for proper installations of the
VGA utility, LAN utility, Sound utility, and Flash BIOS Update. It also
describes the Watchdog-timer configuration.
Chapter 4 Award BIOS Setup
This chapter indicates you how to set up the BIOS configurations.
Appendix A Expansion Bus
This Appendix introduces you the expansion bus for SHB connector.
Appendix B Technical Summary
This section gives you the information about the Technical maps.
Page: 1-2
PSB-701LF USER
'
S MANUAL
