Tpm Connector - Intel PSB-701LF User Manual

2-21. TPM CONNECTOR

JP12: TPM Connector
PIN
1
3
5
7
9
11
13
15
17
19
PSB-701LF USER
ASSIGNMENT
LCLK
LFRAMEJ
LRESTJ
LAD3
VCC3_3
LAD0
NC
3_3USB
GND
LPCPDJ
'
S MANUAL
Chapter 2 Hardware Configuration
PIN ASSIGNMENT
2 GND
4 NC
6 NC
8 LAD2
10 LAD1
12 GND
14 NC
16 SERIRQ
18 CLKRUN
20 NC
Page: 2-15
