Chapter 2 Hardware Configuration
2-6. KEYBOARD AND PS/2 MOUSE CONNECTOR
DIN1 : Keyboard or PS/2 Mouse Connector
DIN connector can support keyboard, Y-cable, or PS/2 Mouse, user may
select the right device to used on "Keyboard or PS/2 Mouse Selection".
The pin assignments are as follows :
PIN
1
2
3
4
5
6
2-7. KEYBOARD OR PS/2 MOUSE SELECTION
JP9 : Keyboard or PS/2 Mouse Selection
For Y-Cable user, please set the jumper same as AT keyboard.
The jumper settings are as follows:
DEVICE TYPE
AT KEYBOARD
PS/2 MOUSE
*** Manufactory default -- AT Keyboard
Page: 2-8
ASSIGNMENT
Keyboard
PS/2 Mouse
KBDATA
MSDATA
GND
5VSB
KBCLK
MSCLK
JUMPER SETTING
(pin closed)
3-5
4-6
1-3
2-4
MSDATA
MSDATA
GND
5VSB
MSCLK
MSCLK
JUMPER
ILLUSTRATION
PSB-701LF USER
'
S MANUAL
