Summary of Contents for Intel PSB-701LF
- Page 1 USER’S MANUAL PSB-701LF Intel Core 2 Duo/Quad ® Full Size CPU Card With VGA/Sound/2LAN PSB-701LF M1...
- Page 2 Copyright Notice PSB-701LF Intel® Core 2 Duo/Quad Full Size CPU Card With VGA/ Sound/ 2LAN OPERATION MANUAL COPYRIGHT NOTICE This operation manual is meant to assist both Embedded Computer manufacturers and end users in installing and setting up the system. The information contained in this document is subject to change without any notice.
-
Page 3: Fcc Notice
Copyright Notice FCC NOTICE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 4: Table Of Contents
Contents TABLE OF CONTENTS CHAPTER 1 INTRODUCTION About This Manual ............System Specification ............Safety Precautions ............CHAPTER 2 HARDWARE CONFIGURATION Jumper & Connector Quick Reference Table ....Component Locations ............ How to Set the Jumpers ..........COM Port Connector ……..…………………………... RS232/422/485(COM2) Selection ........ - Page 5 Introduction …………..........…..VGA Driver Utility ……………………………….…… Flash BIOS Update ..........…..LAN Driver Utility …...........…..Sound Driver Utility …………………………………… Intel Chipset Software Installation Utility …..……..….. USB2.0 Software Installation Utility ………………….. Watchdog Timer Configuration ……………………….. 3-10 CHAPTER 4 AWARD BIOS SETUP Introduction ..............
-
Page 6: Chapter 1 Introduction
CHAPTER INTRODUCTION This chapter gives you the information for PSB-701LF. It also outlines the System specifications. Section includes: About This Manual System Specifications Safety Precautions Experienced users can skip to chapter 2 on page 2-1 for a Quick Start. Page:1-1... -
Page 7: About This Manual
Chapter 1 Introduction 1-1. ABOUT THIS MANUAL Thank you for purchasing our PSB-701LF Intel® Core 2 Duo/ Core 2 Quad Full Size CPU Card enhanced with VGA/Sound/2LAN, which is fully PC / AT compatible. The PSB-701LF provides faster processing speed, greater expandability and can handle more tasks than before. This manual is designed to assist you how to install and set up the system. -
Page 8: System Specification
Chapter 1 Introduction 1-2. SYSTEM SPECIFICATIONS CPU (LGA775): Intel® Core 2 Quad/ Core 2 Duo/ Celeron M with LGA775 CPU socket. (Support Process Technology of Intel: 65nm, 45nm). Auto detect voltage regulator. CHIPSET : Intel® Q35 + ICH9DO + FWH (FSB:800/1066/1333MHz). - Page 9 10 port, support USB 2.0. 6 connectors are on SHB and 4 ports signals be linked to gold fingers. LAN ADAPTER : Dual Ports to support 100/1000Mbps with Intel® 82566DM, Intel® 82573L. Support Wake-on-LAN wtih ATX power SOUND : High Definition Audio with Realtek ALC262 IC.
-
Page 10: Safety Precautions
3. Disconnect power when you change any hardware devices. For instance, when you connect a jumper or install any cards, a surge of power may damage the electronic components or the whole system. ′ Page: 1-5 PSB-701LF USER S MANUAL... -
Page 11: Chapter 2 Hardware Configuration
CHAPTER HARDWARE CONFIGURATION ** QUICK START ** Helpful information describes the jumper & connector settings, and component locations. Section includes: Jumper & Connector Quick Reference Table Component Locations Configuration and Jumper settings Connector’s Pin Assignments Page 2-1... -
Page 12: Jumper & Connector Quick Reference Table
Memory Installation ........…..……… DIMM1, DIMM2 Sound Connector ………………………….…………… AUDIO1 CD Audio-In Connector ……………………………….. CD_IN1 LVDS1 LVDS Connector ………………………………………. LVDS Voltage Selection ………………………………. JP1, JP5 PCI Express / SDVO Interface Selection ……………… Reserved Pin …………………………………………… ′ Page: 2-2 PSB-701LF USER S MANUAL... -
Page 13: Component Locations
Chapter 2 Hardware Configuration 2-2. COMPONENT LOCATIONS PSB-701LF Connector, Jumper and Component locations ′ Page: 2-3 PSB-701LF USER S MANUAL... -
Page 14: How To Set The Jumpers
You can connect PIN1 & PIN2 to create one setting by shorting. You can either connect PIN2 & PIN3 to create another setting. The same jumper diagrams are applied all through this manual. The figure below shows what the manual diagrams look and what they represent. ′ Page: 2-4 PSB-701LF USER S MANUAL... - Page 15 Jumper Block looks like this JUMPER SETTINGS 2 pin Jumper close(enabled) Looks like this 3 pin Jumper 2-3 pin close(enabled) Looks like this Jumper Block 1-2 pin close(enabled) Looks like this ′ Page: 2-5 PSB-701LF USER S MANUAL...
-
Page 16: Com Port Connector
COM2 : COM2 Connector The COM2 is selectable as RS-232/422/485. The pin assignment is as follows : ASSIGNMENT RS-232 RS-422 RS-485 COM2_DCD# COM2_RX COM2_TX COM2_DTR# COM2_DSR# RTS- COM2_RTS# RTS+ COM2_CTS# CTS+ COM2_RI# CTS- ′ Page: 2-6 PSB-701LF USER S MANUAL... -
Page 17: Rs232/422/485(Com2) Selection
This connector is used to set the COM2 function. The jumper settings are as follows : COM 2 Jumper Settings Jumper Function (pin closed) Illustrations RS-232 All Open RS-422 1-2, 3-4, 9-10 RS-485 1-2, 5-6, 7-8 *** Manufacturing default -- RS-232. ′ Page: 2-7 PSB-701LF USER S MANUAL... -
Page 18: Keyboard And Ps/2 Mouse Connector
For Y-Cable user, please set the jumper same as AT keyboard. The jumper settings are as follows: JUMPER SETTING JUMPER DEVICE TYPE (pin closed) ILLUSTRATION AT KEYBOARD PS/2 MOUSE *** Manufactory default -- AT Keyboard ′ Page: 2-8 PSB-701LF USER S MANUAL... -
Page 19: External Keyboard Connector
The pin assignment is as follows : ASSIGNMENT RST_BTN 2-10. HARD DISK DRIVE LED CONNECTOR JP7 (1, 3) : Hard Disk Drive LED Connector The pin assignment is as follows : ASSIGNMENT HD_LED+ HD_LED- ′ Page: 2-9 PSB-701LF USER S MANUAL... -
Page 20: Atx Power Button
The pin assignment is as follows : ASSIGNMENT SPK_VCC SPEAKER SIGNAL SPEAKER SIGNAL SPEAKER SIGNAL 2-13. POWER LED CONNECTOR JP7 (2, 4) : Power LED Connector The pin assignment is as follows: ASSIGNMENT PW_LED+ PW_LED- ′ Page: 2-10 PSB-701LF USER S MANUAL... -
Page 21: Keylock Connector
2-14. KEYLOCK CONNECTOR JP7 (13, 15) : Keylock Connector The pin assignment is as follows: ASSIGNMENT KEYLOCK 2-15. EXTERNAL SMI CONNECTOR JP7 (17,19) : External SMI Connector The pin assignment is as follows: ASSIGNMENT SLP_BTN ′ Page: 2-11 PSB-701LF USER S MANUAL... -
Page 22: Clear Cmos Data Selection
“Clear CMOS” as illustrated above. After five to six seconds, set the jumper back to “Normal” and power-on the computer. 2-17. CPU FAN CONNECTOR CPU_FAN1 : CPU Fan connector The pin assignment is as follows: ASSIGNMENT VCC12 LPC1_FANIO1 LPC1_FANPWM1 ′ Page: 2-12 PSB-701LF USER S MANUAL... -
Page 23: System Fan Connector
SYS_FAN1 : System Fan connector The pin assignment is as follows: ASSIGNMENT VCC12 LPC1_FANIO2 2-19. INVERTER CONNECTOR INV1 : Inverter Connector The pin assignment is as follows: ASSIGNMENT +12V ENABKL(Inverter backlight ON/OFF control signal) ′ Page: 2-13 PSB-701LF USER S MANUAL... -
Page 24: Printer Connector
As to link the Printer to the card, you need a cable to connect both DB25 connector and parallel port. The pin assignments are as follows : ASSIGNMENT ASSIGNMENT AFD# PDR0 ERROR# PDR1 PAR_INIT# PDR2 SLIN# PDR3 PDR4 PDR5 PDR6 PDR7 ACK# BUSY SLCT ′ Page: 2-14 PSB-701LF USER S MANUAL... -
Page 25: Tpm Connector
Chapter 2 Hardware Configuration 2-21. TPM CONNECTOR JP12: TPM Connector ASSIGNMENT ASSIGNMENT LCLK LFRAMEJ LRESTJ LAD3 LAD2 VCC3_3 LAD1 LAD0 3_3USB SERIRQ CLKRUN LPCPDJ ′ Page: 2-15 PSB-701LF USER S MANUAL... -
Page 26: Vga Connector
Chapter 2 Hardware Configuration 2-22. VGA CONNECTOR VGA1: VGA Connector ASSIGNMENT GMCH_CRTRED GMCH_GRTGREEN GMCH_CRTBLUE GMCH_CRTVCC_L GMCH_CRTDATA GMCH_HSYNC GMCH_VSYNC GMCH_CRTCLK ′ Page: 2-16 PSB-701LF USER S MANUAL... -
Page 27: Serial Ata Connector
Chapter 2 Hardware Configuration 2-23. SERIAL ATA CONNECTOR SATA1, SATA2, SATA3, SATA4 : The PSB-701LF possesses four Serial ATA Connector. The pin assignments are as follows: SATA1: ASSIGNMENT SATAHDR_TXP0 SATAHDR_TXN0 SATAHDR_RXN0 SATAHDR_RXP0 SATA2: ASSIGNMENT SATAHDR_TXP1 SATAHDR_TXN1 SATAHDR_RXN1 SATAHDR_RXP1 ′ Page: 2-17... - Page 28 Chapter 2 Hardware Configuration SATA3: ASSIGNMENT SATAHDR_TXP2 SATAHDR_TXN2 SATAHDR_RXN2 SATAHDR_RXP2 SATA4: ASSIGNMENT SATAHDR_TXP3 SATAHDR_TXN3 SATAHDR_RXN3 SATAHDR_RXP3 ′ Page: 2-18 PSB-701LF USER S MANUAL...
-
Page 29: Universal Serial Bus Connector
USB1: Universal Serial Bus Connector The pin assignments are as follows: ASSIGNMENT USB1_VCC5 USBN0_L USBP0_L USB1_VCC5 USBN1_L USBP1_L USB2: Universal Serial Bus Connector The pin assignments are as follows: ASSIGNMENT USB2_VCC5 USBN2_L USBP2_L USB2_VCC5 USBN3_L USBP3_L ′ Page: 2-19 PSB-701LF USER S MANUAL... - Page 30 Chapter 2 Hardware Configuration USB3: Universal Serial Bus Connector The pin assignments are as follows: ASSIGNMENT USB3_VCC5 USBN4_L USBP4_L USB3_VCC5 USBN5_L USBP5_L ′ Page: 2-20 PSB-701LF USER S MANUAL...
-
Page 31: Lan Connector
Left Side LED Green Color On 10/100 LAN Speed Indicator Orange Color On Giga LAN Speed Indicator No LAN switch/ hub connected. Right Side LED Yellow Color Blinking LAN Message Active No LAN Message Active ′ Page: 2-21 PSB-701LF USER S MANUAL... - Page 32 Left Side LED Green Color On 10/100 LAN Speed Indicator Orange Color On Giga LAN Speed Indicator No LAN switch/ hub connected. Right Side LED Yellow Color Blinking LAN Message Active No LAN Message Active ′ Page: 2-22 PSB-701LF USER S MANUAL...
-
Page 33: Atx Power Connector
ATX_PW1 : ATX 12V Connector The pin assignments are as follows: ASSIGNMENT +12V +12V 2-27. MEMORY INSTALLATION PSB-701LF CPU Card can support up to 4GB in two DIMM sockets. DRAM BANK CONFIGURATION DIMM 1 DIMM 2 TOTAL MEMORY 256MB 256MB... -
Page 34: Sound Connector
ASSIGNMENT AC97_MIC-IN AUDIO_GND AUDIO_GND AUDIO_GND AC97_LINE-L AC97_LINE-R AUDIO_GND AUDIO_GND AC97_SPK-L AC97_SPK-R 2-29. CD AUDIO-IN CONNECTOR CD_IN1 : CD Audio-In Connector The pin assignments are as follows: ASSIGNMENT CD L CDGND CDGND CD R ′ Page: 2-24 PSB-701LF USER S MANUAL... -
Page 35: Lvds Connector
LVDS1 : LVDS Connector. The pin assignments are as follows: ASSIGNMENT ASSIGNMENT LVDS_VCC CLKBM CLKBP YBM2 YBP2 YBM1 YBP1 YBP3 YBM3 YBP0 YBM0 CLKAP CLKAM YAP2 YAM2 YAP1 YAM1 YAP0 YAM0 YAP3 YAM3 LVDS_VCC LVDS_VCC ′ Page: 2-25 PSB-701LF USER S MANUAL... -
Page 36: Lvds Panel Voltage Selection
Chapter 2 Hardware Configuration 2-31. LVDS PANEL VOLTAGE SELECTION JP2 : LVDS Panel Voltage Selection. The selections are as follows: JUMPER SETTING JUMPER FUNCTION (pin closed) ILLUSTRATION LVDS_VCC3 LVDS_VCC5 *** Manufactory default --- LVDS_VCC3. ′ Page: 2-26 PSB-701LF USER S MANUAL... -
Page 37: Pci Express/ Sdvo Interface Selection
ILLUSTRATION JP15 JP16 2-3, 5-6, 8-9, 11-12, 14-15, open 17-18, 20-21, PCI Express 23-24, 26-27, 29-30 1-2, 4-5, 7-8, 10-11, 13-14, 1-2, 3-4 16-17, 19-20, SDVO 22-23, 25-26, 28-29 *** Manufacturing Default: SDVO ′ Page: 2-27 PSB-701LF USER S MANUAL... - Page 38 Sound driver, and flash BIOS update. It also describes on how to configuration the watchdog timer. Section includes: Introduction. VGA Driver Utility Flash BIOS Update LAN Driver Utility Sound Driver Utility Intel® Chipset Software Installation Utility USB2.0 Chipset Software Installation Utility Watchdog Timer Configuration Page: 3-1...
-
Page 39: Introduction
Chapter 3 Software Configuration 3-1. INTRODUCTION Enclosed with our PSB-701LF package is our driver utility, which may comes in a form of a CD ROM disc or floppy diskettes. For CD ROM disc user, you will only need some of the files contained in the CD ROM disc,... -
Page 40: Vga Driver Utility
Chapter 3 Software Configuration 3-2. VGA DRIVER UTILITY The VGA interface embedded with our PSB-701LF can support a wide range of display. You can display CRT, PCI-E (SDVO) simultaneously with the same mode. 3-2-1. Installation of VGA Driver: To install the VGA Driver, simply follow the following steps: 1. -
Page 41: Flash Bios Update
Chapter 3 Software Configuration 3-3. FLASH BIOS UPDATE 3-3-1. System BIOS Update: Users of PSB-701LF can use the program “ ” contained in CD AWDFLASH.EXE ROM for BIOS update. This is found in .EXE. D:\DRIVER\FLASH\AWDFLASH 3-3-2. To update BIOS : (1) Install “... - Page 42 Select “Y”, and the BIOS will be renewed. When you are refreshing your BIOS, do not turn off or reset the system, or you will damage the BIOS. After you have completed all the programming. Please turn off the system. Then the Flash BIOS is fully implemented. ′ Page:3-5 PSB-701LF USER S MANUAL...
-
Page 43: Lan Driver Utility
Chapter 3 Software Configuration 3-4. LAN DRIVER UTILITY 3-4-1. Introduction PSB-701LF is enhanced with LAN function that can support various network adapters. Installation programs for LAN drivers are listed as follows: For more details on Installation procedure, please refer to Readme.txt file found on LAN DRIVER UTILITY. -
Page 44: Sound Driver Utility
“D:\Sound\pathname” refers to the full path to the source files. 3. Click on the OK button or press the ENTER key. 4. Click on the “Next” and OK prompts as they appear. 5. Reboot the system to complete the driver installation. ′ Page:3-7 PSB-701LF USER S MANUAL... -
Page 45: Intel Chipset Software Installation Utility
3-6. INTEL® C HIPSET SOFTWARE INSTALLATION UTILITY 3-6-1. Introduction The Intel® Chipset Software Installation Utility installs to the target system the Windows* INF files that outline to the operating system how the chipset components will be configured. This is needed for the... -
Page 46: Usb2.0 Software Installation Utility
3-7. USB2.0 SOFTWARE INSTALLATION UTILITY 3-7-1. Installation of Utility for Windows 2000/XP Intel USB 2.0 Enhanced Host Controller driver can only be used on Windows 2000 and Windows XP on Intel Desktop boards. It should be installed right after the OS installation, kindly follow the following steps: 1. -
Page 47: Watchdog Timer Configuration
NMI function. If you want to stop watchdog timer, you can read I/O port 440H, then timer will stop count. In PSB-701LF watchdog function, You must write your program so when it writes I/O port address 444H and 448H for enable watchdog. The timer's intervals have a tolerance of 25% so you should program an instruction that will refresh the timer about every second. - Page 48 CHAPTER AWARD BIOS SETUP This chapter shows how to set up the Award BIOS. Section includes: Introduction Entering Setup The Standard CMOS Features The Advanced BIOS Features The Advanced Chipset Features Integrated Peripherals Power Management Setup PC Health Status Frequency Control Load Fail-Safe Defaults Load Optimized Defaults Password Setting...
-
Page 49: Introduction
4-1. INTRODUCTION This chapter will show you the function of the BIOS in managing the features of your system. The PSB-701LF Intel Core 2 Duo/Quad Full Size CPU Card is equipped with the BIOS for system chipset from Phoenix - Award Software Inc. -
Page 50: Entering Setup
You may use the cursor the up/down keys to highlight the individual menu items. As you highlight each item, a brief description of the highlighted selection will appear at the bottom of the screen. ′ Page: 4-3 PSB-701LF USER S MANUAL... -
Page 51: The Standard Cmos Features
< Hour >, < Minute >, and < Second >. Use 24 hour clock format, i.e., for PM numbers, add 12 to the hour. For example: 4: 30 P.M. You should enter the time as 16:30:00. ′ Page: 4-4 PSB-701LF USER S MANUAL... - Page 52 Auto: The BIOS automatically determines the optimal mode. Normal: Maximum number of cylinders, heads, sectors supported are 1024, 16 and 63. Large: For drives that do not support LBA and have more than 1024 cylinders. ′ Page: 4-5 PSB-701LF USER S MANUAL...
- Page 53 BASE MEMORY: Displays the amount of conventional memory detected during boot up. EXTENDED MEMORY: Displays the amount of extended memory detected during boot up. TOTAL MEMORY: Displays the total memory available in the system. ′ Page: 4-6 PSB-701LF USER S MANUAL...
-
Page 54: The Advanced Bios Features
BIOS Features Setup Screen The “BIOS FEATURES SETUP” allow you to configure your system for basic operation. The user can select the system’s boot-up sequence and security. A brief introduction of each setting is given below. ′ Page: 4-7 PSB-701LF USER S MANUAL... - Page 55 Do not type anything and just press <Enter>, it will disable security. Once the security is disabled, the system will boot and you can enter Setup freely. ′ Page: 4-8 PSB-701LF USER S MANUAL...
-
Page 56: Advanced Chipset Features
Multiprocessor Specification (MPS) that the motherboard will use. The MPS is a specification by which PC manufacturers design and build Intel architecture systems with two or more processors. 4-5. ADVANCED CHIPSET FEATURES Choose the〝ADVANCED CHIPSET FEATURES〞from the main menu, the screen shown as below. - Page 57 Precharge Delay This setting controls the precharge delay, which determines the timing delay for DRAM precharge SYSTEM MEMORY FREQUENCY: Allow to choose different frequency of memory module. VT-d: Intel Virtualization Technology for Directed I/O. ′ Page: 4-10 PSB-701LF USER S MANUAL...
- Page 58 The message show enable or disable IDE Redirection. PLATFORM MNG SELECTION: The message shows which managed function user choose. DVMT MODE: Intel Dynamic Video Memory Technology Mode. DVMT/FIXED MEMORY SIZE: DVMT Memory Size Select. PCI SERR# NMI To Enable/Disable the PCI SERR# interrupt ′...
-
Page 59: Integrated Peripherals
If bios setup menu item supports USB device boot, it will cause Win9x detects the same storages twice when the system is rebooted, and USB HDD will fail. Note: this cause just happen under Win9x, the phenomenon is a limitation. ′ Page: 4-12 PSB-701LF USER S MANUAL... - Page 60 Controller Interface (AHCI) or RAID mode, the SATA controller is set to Native mode. Configuration options: [IDE] [RAID] [AHCI] 2. LEGACY MODE SUPPORT Certain OS (Windows 9X/ME) is not supported under Native mode ′ Page: 4-13 PSB-701LF USER S MANUAL...
- Page 61 Select a DMA channel for the parallel port for use during ECP mode. 5. PWRON AFTER PWR-FAIL This item allows you to select if you want to power on the system after power failure. The choice:Off,On,Former-Sts. ′ Page: 4-14 PSB-701LF USER S MANUAL...
- Page 62 [Auto]: According to contents of USB MSD decide boot up type [FDD Mode]: The USB MSD always boot up as floppy disk '[HDD Mode]: The USB MSD always boot up as hard disk. ONBOARD LAN 2 CONTROLLER: Enable the LAN controller. ′ Page: 4-15 PSB-701LF USER S MANUAL...
-
Page 63: Power Management Setup
Pressing the power button for more than 4 seconds forces the system to enter the Soft-Off state when the system has “hung”. The choices are Delay 4 Sec and Instant-Off. PME EVENT WAKE UP: An input signal PME wake the system from the soft-off state ′ Page: 4-16 PSB-701LF USER S MANUAL... -
Page 64: Pc Health Status
1.8V/3.3V/12V / 5V : Show you the voltage of 1.8V/3.3V/12V/5V. SYSTEM/CPU TEMPERATURE: This item shows you the current System/CPU temperature. CPU/SYSTEM/POWER FAN: This item shows you the current CPU/ SYSTEM /Power FAN speed. ′ Page: 4-17 PSB-701LF USER S MANUAL... -
Page 65: Load Fail-Safe Defaults
When you press <Enter> on this category, you get a confirmation dialog box with a message similar to the following: Load Optimized Defaults ( Y/N ) ? N Pressing "Y" loads the default values that are factory setting for optimal performance system operations. ′ Page: 4-18 PSB-701LF USER S MANUAL... -
Page 66: Password Setting
PASSWORD DISABLED!!! Press any key to continue... Press the < Enter > key again and the password will be disabled. Once the password is disabled, you can enter Setup freely. ′ Page: 4-19 PSB-701LF USER S MANUAL... -
Page 67: Save & Exit Setup
You may always call up the setup program at any time to adjust any of the individual items by pressing the <Del> key during boot up. ′ Page: 4-20 PSB-701LF USER S MANUAL... -
Page 68: Exit Without Saving
Set Supervisor Password ►Integrated Peripherals word Quit Without Saving (Y/N)? N ►Power Management etup ►PC Health Status Saving Esc : Quit ↑↓→← : Select Item F10 : Save & Exit Setup Abandon all Datas ′ Page: 4-21 PSB-701LF USER S MANUAL... -
Page 69: Shb Connector Pin Assignment
APPENDIX EXPANSION BUS This appendix indicates the pin assignments. Section includes: SHB Connector Pin Assignment Page: A-1... - Page 70 +12V +3.3V +3.3V AD07 AD05 a_PETn0 +12V +12V +3.3V +3.3V AD04 a_PERp0 +12V +12V +3.3V +3.3V AD02 a_PERn0 +12V +12V +3.3V +3.3V AD03 AD01 a_PETp1 +12V +12V +3.3V +3.3V AD00 a_PETn1 +3.3V +3.3V ′ Page: A-2 PSB-701LF USER S MANUAL...
- Page 71 +12V a_PETn7 +12V +12V a_PERp7 +12V +12V a_PERn7 +12V +12V RSVD* +12V +12V +3.3V +3.3V +12V +12V +3.3V +3.3V +12V +12V +3.3V +3.3V +12V +12V +3.3V +3.3V +12V +12V +3.3V +3.3V +12V +12V ′ Page: A-3 PSB-701LF USER S MANUAL...
- Page 72 APPENDIX TECHNICAL SUMMARY This section introduce you the maps concisely. Section includes: Block Diagram Interrupt Map RTC & CMOS RAM Map Timer & DMA Channels Map I / O & Memory Map Page: B-1...
-
Page 73: Block Diagram
Appendix B Technical Summary BLOCK DIAGRAM ′ Page: B-2 PSB-701LF USER S MANUAL... -
Page 74: Interrupt Map
Appendix B Technical Summary INTERRUPT MAP ASSIGNMENT System TIMER Keyboard Cascade Serial port 2 Serial port 1 Available Floppy Parallel port 1 RTC clock Available Available Available PS/2 Mouse Math coprocessor IDE1 IDE2 ′ Page: B-3 PSB-701LF USER S MANUAL... -
Page 75: Rtc & Cmos Ram Map
Extension memory low byte Extension memory high byte Reserved for extension memory low byte Reserved for extension memory high byte Date Century byte Information Flag 34-3F Reserve 40-7f Reserved for Chipset Setting Data ′ Page: B-4 PSB-701LF USER S MANUAL... -
Page 76: Timer & Dma Channels Map
TIMER & DMA CHANNELS MAP Timer Channel Map : Timer Channel Assignment System timer interrupt DRAM Refresh request Speaker tone generator DMA Channel Map : DMA Channel Assignment Available Available Floppy Available Cascade Available Available Available ′ Page: B-5 PSB-701LF USER S MANUAL... -
Page 77: I/O & Memory Map
Parallel port-2 2B0-2DF Graphics adapter controller 2F8-2FF Serial port-2 360-36F Net work ports 378-37F Parallel port-1 3B0-3BF Monochrome & Printer adapter 3C0-3CF EGA adapter 3D0-3DF CGA adapter 3F0-3F7 Floppy disk controller 3F8-3FF Serial port-1 ′ Page: B-6 PSB-701LF USER S MANUAL...
