6. MENU STRUCTURE

6.1 The operator menu

Fig. 24
Operator menu structure
If your machine has a payment system (optional), you can now
change the machine's setting from free to paid.
Please set the present date and time. The machine does not
automatically adjust from winter to summer time and vice versa.
The machine can be set automatically. The main switch must be on.
If the machine is turned off by the timer, the machine is automatically
set to standby. The boiler then keeps the water at 60°C and the
operating panel is disabled.
To be continued
on the next page
Escape (back without con¿ rming any changes)
Previous (menu item / increase value)
Next (menu item / decrease value)
Enter (con¿ rm menu choice)
Range Factory setting
> Yes > Yes
No
hour : min
dd - mm - yyyy
00:00-23:59 00:00 = not active
00:00-23:59
00:00-23:59 00:00 = not active
00:00-23:59
00:00-23:59 00:00 = not active
00:00-23:59
68 07/2009 Rev. 0.9
Operator menu structure
Use this menu to maintain the counter. The reset function is only available if
it has been activated by the service engineer.
The quick recipe menu is only available if it has been activated by the service
engineer. It allows you to easily set the volume and strength of coffee, milk and
sugar per recipe (drink button) yourself. Only the ingredients that apply to the
recipe in question are visible.
For more information about the use of the quick recipe, see chapter 6.2.
Once the permanent ¿ lter of the brewer unit reaches the maximum
number of brews, this ¿ lter must be replaced. After replacing the
permanent ¿ lter, reset the 'replace brewer ¿ lter' indication.
07/2009 Rev. 0.9
Range Factory settings
0-99999 cups
0-99999 cups
0-99999 cups
0-99999 cups
0-99999
0-99999
if available!
50-200 ml 120 ml
-20% +20% 0%
-20% +20% 0%
-20% +20% 0%
-20% +20% 0%
-20% +20% 0%
Only applicable for the
service engineer.
Only applicable for the
service engineer.
69
