7.6 Automatic disabling functions

During use, the following display messages (¿ g. 39) can
appear and automatically disable the drink selection
buttons:
1 Boiler ¿ lling up; Water pressure is gone or the
water tank (stand-alone setup) is empty.
2. Boiler heating up; The boiler temperature is
(temporarily) too low because of too much water
consumption. As soon as the temperature is ¿ ne,
the message automatically disappears and the drink
selection buttons will work again.
3. Drip tray is full; Once the drip tray is emptied, the
message automatically disappears and the drink
selection buttons will work again.
4. Waste bin is full; The maximum amount of cups
of coffee to be made that ¿ ts the waste bin has been
reached. Empty waste bin. The cup counter
automatically resets as you replace the tray.
5. Waste bin missing; The waste bin cannot be
detected. Check the waste bin.
6. Door open; For safety reasons the machine is
automatically switched off as soon as the door is
opened. The machine can be switched on with the
door open by using the door pen (see chapter 8.1).
7. Standby; The machine is set to standby.
This function could have been set manually (see
chapter 5.2-A) or automatically (see chapter 6.1
Operator menu item 1.2 Timer settings).
7.7 Display messages during use
The following display messages (¿ g. 40) can appear
immediately after the machine is switched on:
Clean brewer;
1 The brewer unit must be cleaned.
Text message when: brewer NOT cleaned after 300
coffee's or 5 day's.
See chapter 8.3.1 Cleaning the brewer unit. Once
the cleaning programme has been carried out, this
display message disappears.
Replace brewer ¿ lter;
2. The brewer ¿ lter
(or permanent ¿ lter) has reached the maximum
number of brews and should be replaced as a
precaution.
See chapter 8.7.1 How to replace the brew ¿ lter and
how to erase the display message.
Descaling / ¿ lter;
3. The machine must be
descaled or the water ¿ lter must be replaced.
Contact your dealer for technical maintenance.
1
2
3
4
5
6
7
1
2
3
76 07/2009 Rev. 0.9
8. MAINTENANCE
WARNING
The device must not be submerged or hosed down.
Do not leave the device during maintenance.
You can follow the HACCP hygiene code instructions of
your organisation for the use of cleaning products. Look
or search under object: Machine of hot drinks.
Don't give bacteria a chance: maintain your device
according to regulations!

8.1 Door switch

WARNING
Take into account the brewer's moving parts when
the machine is in use with the service pin.
The brewer motor is extremely powerful and can jam
hands or fingers!
The machine has a door switch that turns the machine
off when the door is opened.
[Out of order. Door open]
The machine can be turned on with the door open (for
example for cleaning activities) by inserting the supplied
Fig. 39
service pin (¿ g. 41) into the door switch.
8.2 Rinsing programmes
The machine has two rinsing programmes for the daily
rinsing of the brewer unit (¿ g. 42-1) and mixer system
(¿ g. 42-2).
We advise you to run the rinsing programme both at
the beginning and at the end of normal of¿ ce hours.
The rinsing water must be collected in a rinsing tray
below the machine.
Fig. 40
07/2009 Rev. 0.9
Fig. 41
1
2
Fig. 42
77
