Animo OptiFresh 1 Manual page 22

WARNING
In order to descale the water reservoir, the device
must be opened. This will expose live parts of the
machine, which can be touched easily. This can lead
to highly dangerous situations!
WARNING
The device must not be submerged or hosed down.
Always stay with the device during maintenance
work.
9. SETTING THE SERVICE MOMENT
During the installation of the device, your service engi-
neer set a time for the device to be serviced.
The dispensed drinks are counted during use.
If the set time for service is reached, the display
shows the following message: Descale / ¿ lter
(¿ g. 56).
When this message appears, you can continue to use
the device as usual.
The message indicates that the device must be des-
caled. If a water ¿ lter was ¿ tted (advised), this is also
an indication that the ¿ lter must be replaced.
For safety reasons, users are not advised to descale
the machine and/or replace the ¿ lter. We advise you
to have an authorised service engineer descale and
maintain the device.
Water hardness table
Water Hardness
Quality
°D °F °C mmol/l
Very hard 18-30 32-55 11-18 3,2-5,3
Hard 12-18 22-32 7-18 2,2-3,2
Average 8-12 15-22 5-7 1,4-2,2
Soft 4-8 7-15 2-5 0,7-1,4
Very soft 0-4 0-7 0-2
Limescale
Indicator ...cups
mgCaCo3/l
321- 536 5000
214-321 8500
268-214 12.500*
72-268 20.500
0- 0,7 0-72 0 = off
88
10. DRY BOIL PROTECTION
The device has a dry boil protection that is accessible
from the outside. It is located at the back of the device
(¿ g. 57). The dry boil protection turns off the heating
element if the temperature is too high. This is usually
caused by not descaling the device in time. If the
appliance is no longer heating the water, please do the
following:
1. Allow the device to cool down.
2. Remove the black protective knob (¿ g. 57-2).
3. Now press the visible button (¿ g. 57-1) and push
the protective knob back into place.
If the safety device turned off the machine and the
message [Descale / ¿ lter] is visible when restarting the
machine, then have the machine descaled. See chapter
9. Time for service.
11. TRANSPORT / STORAGE
Please do the following before transporting or putting
the device in storage.
1. Carry out the brewer and mixer unit cleaning pro
gramme.
2. Clean the ingredient canister(s), mixer system,
leaking tray and casing as described in chapter
Fig. 56
8. Maintenance.
3. Switch off the device and remove the plug from the
wall socket.
4. Close the water supply tap and disconnect the
water connection tube.
5. Drain the water reservoir (approx. 3 litres) by using
the draining tube.
6. Put the parts mentioned in point 5 back in their
place.
7. The device is now ready for transport.
8. Before reinstalling the device, please ensure chapter
3. Installation is followed.
Table 4
07/2009 Rev. 0.9
07/2009 Rev. 0.9
Reset Reset
Fig. 57
~
Volt
Fig. 58
89
1 1
2 2
1 1
