  • Page 1 UPER ERVER ® 1028TP-DC1(R/TR/FR) USER’S MANUAL Revision 1.0a...
  • Page 2 This product, including software and documentation, is the property of Supermicro and/or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except as expressly permitted by the terms of said license.

  • Page 3: About This Manual

    About this Manual This manual is written for professional system integrators and PC technicians. It provides information for the installation and use of the SuperServer. Installation and maintainance should be performed by experienced technicians only. Please refer to the server specifications page on our Web site for updates on supported memory, processors and operating systems (www.supermicro.com).

  • Page 4: Table Of Contents

    Power Supply ....................1-5 Cooling ......................1-5 Expansion Slots ....................1-5 Mounting Rails ....................1-5 Contacting Supermicro ..................1-6 Chapter 2 Rack Installation ..............2-1 Unpacking the System ..................2-1 Preparing for Setup ..................2-1 Choosing a Setup Location ................2-1 Warnings and Precautions ................
  • Page 5 Preface Chapter 3 System Interface ..............3-1 Overview ......................3-1 Control Panel Buttons ..................3-2 Power ......................3-2 UID Switch ...................... 3-2 Control Panel LEDs ..................3-2 Power ......................3-2 NIC ........................3-2 Information LED ....................3-3 Overheating ..................... 3-3 Overheat Temperature Setting ..............3-3 Responses ....................
  • Page 6 UPER ERVER 1028TP-DC1(R/TR/FR) Manual Installing Memory .................... 5-9 Memory Support ....................5-9 Motherboard Details ..................5-12 X10DRT-(P/PT/PIBF) Motherboard Quick Reference ........5-13 Connector Definitions ..................5-14 Jumper Settings .................... 5-16 Explanation of Jumpers ................5-16 Onboard Indicators ..................5-18 5-10 PCI-Express and SATA Connections ............

  • Page 7: Chapter 1 Introduction

    Chapter 1 Introduction Overview The SuperServer 1028TP-DC1(R/TR/FR) is a high-end server comprised of two main subsystems: the SC809H--R1K05P 1U server chassis and the X10DRT-(P/PT/PIBF) dual processor motherboard in two hot-swap nodes. Refer to the Supermicro web site for information on operating systems that have been certified for use with the system (www.supermicro.com).

  • Page 8: Serverboard Features

    1-1 for a block diagram of the chipset.) Processors The motherboard supports single or dual Intel Xeon E5-2600 v3/v4 Series processors in LGA2011 sockets (Socket R LGA 2011). Refer to the Supermicro web site for a complete listing of supported processors (www.supermicro.com). Memory...

  • Page 9: Graphics Controller

    I/O ports include a VGA (monitor) port, two USB 3.0 ports, an IPMI dedicated LAN port and two Ethernet ports. Note: For IPMI Configuration Instructions, please refer to the Embedded BMC Configuration User's Guide available at http://www.supermicro.com/support/ manuals/. Graphics Controller The serverboard features an integrated ASpeed 2400 BMC with an integrated VGA/2D graphics controller.

  • Page 10: System Block Diagram

    UPER ERVER 1028TP-DC1(R/TR/FR) User's Manual #1-8 #2-8 #1-7 #2-7 VR12.5 VR12.5 #1-6 #2-6 5 PHASE 5 PHASE #1-5 #2-5 145W 145W #1-4 #2-4 #1-3 9.6G #2-3 #1-2 #2-2 CPU1 CPU2 #1-1 #2-1 DDR-4 DDR-4 DMI2 DMI2 9.6G PCI-E X8 G3 PCI-E X16 G3 PCI-E X8 G3 PCI-E X16 G3...

  • Page 11: Chassis Features

    Chapter 1: Introduction Chassis Features The 1028TP-DC1(R/TR/FR) is built upon the SC809H--R1K05P 1U chassis which features two hot-swap computing node drawers. The following is a general outline of the main features of the chassis. Power Supply The chassis features two (1 + 1) 1000 watt redundant high-efficiency digital power supplies with PMBus 1.2 and 80 Plus Titaniium level certification (PWS-1K05A-1R).

  • Page 12: Contacting Supermicro

    Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML...

  • Page 13: Chapter 2 Rack Installation

    Chapter 2 Rack Installation Chapter 2 Rack Installation This chapter provides instructions for preparing and mounting your chassis in a rack. Unpacking the System Before mounting in a rack, inspect the box the chassis was shipped in and note if it was damaged in any way.

  • Page 14: Warnings And Precautions

    SUPERSERVER 1028TP-DC1(R/TR/FR) User's Manual Warnings and Precautions Rack Precautions • Ensure that the leveling jacks on the bottom of the rack are fully extended to the floor with the full weight of the rack resting on them. • In single rack installations, stabilizers should be attached to the rack.

  • Page 15: Rack Mounting Considerations

    Chapter 2 Rack Installation Rack Mounting Considerations Ambient Operating Temperature If installed in a closed or multi-unit rack assembly, the ambient operating temperature of the rack environment may be greater than the ambient temperature of the room. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer’s maximum rated ambient temperature (TMRA).

  • Page 16: Installing The System Into A Rack

    SUPERSERVER 1028TP-DC1(R/TR/FR) User's Manual Installing the System into a Rack There are a variety of rack units on the market, which may require a slightly different assembly procedure. This rail set fits a rack between 25.6" and 33" deep. The following is a basic guideline for installing the system into a rack with the rack mounting hardware provided.

  • Page 17: Assembling The Outer Rails

    Chapter 2 Rack Installation Assembling the Outer Rails Each outer rail comes in two sections that must be assembled before mounting onto the rack. Assembling the Outer Rails 1. Identify the left and right outer rails by examining the ends, which bend outward. Match the left front outer rail with the left rear outer rail and the same for the right rails.

  • Page 18: Installing The Outer Rails Onto The Rack

    SUPERSERVER 1028TP-DC1(R/TR/FR) User's Manual Installing the Outer Rails onto the Rack Each end of the assembled outer rail includes a bracket with square pegs to fit into your rack holes. If you have an older rack with round holes, these brackets must be removed, and you must use screws to secure the rail to the rack.

  • Page 19: Sliding The Chassis Onto The Rack Rails

    Chapter 2 Rack Installation Sliding the Chassis onto the Rack Rails Installing the Chassis into a Rack 1. Align the rear of the chassis rails with the front of the rack rails and then push evenly on both sides of the chassis. The spring latch engages when the chassis is part way in.

  • Page 20: Installing The Server Into A Telco Rack

    SUPERSERVER 1028TP-DC1(R/TR/FR) User's Manual Installing the Server into a Telco Rack To install the server into a Telco (or “open”) type rack, use L-shaped brackets (p/n MCP-290-00012-0N) on either side of the chassis (four total). 1. Determine how far the server will extend out from the front of the rack. The chassis should be positioned so that the weight is balanced between front and back.

  • Page 21: Chapter 3 System Interface

    Chapter 3: System Interface Chapter 3 System Interface Overview The server includes a control panel on the front that houses power buttons and status monitoring lights. The externally accessible hard drives display status lights. The power supply displays status lights visible from the back of the chassis. Figure 3-1.

  • Page 22: Control Panel Buttons

    SUPERSERVER 1028TP-DC1(R/TR/FR) User's Manual Control Panel Buttons The panel includes two push-buttons, power and UID. Power The main power switch applies or removes primary power from the power supply to the server but maintains standby power. To perform most maintenance tasks, unplug the system to remove all power.

  • Page 23: Information Led

    Some backplanes allow the overheat temperature to be set at 45, 50, or 55 by changing a jumper setting. For more information, consult the backplane user manual at www.supermicro.com. (Click Support, then the Manuals link.) Responses If the server overheats: 1.

  • Page 24: Drive Carrier Leds

    SUPERSERVER 1028TP-DC1(R/TR/FR) User's Manual Drive Carrier LEDs The chassis includes externally accessible drives. Each drive carrier displays two status LEDs on the front of the carrier. LED Color Blinking Pattern Behavior for Device Activity LED Blue Blinking I/O activity Blue...

  • Page 25: Chapter 4 Standardized Warning Statements For Ac Systems

    Only certified technicians should attempt to install or configure components. Read this chapter in its entirety before installing or configuring components in the Supermicro chassis. Some warnings may not apply for your system. These warnings may also be found on our web site at www.supermicro.com/about/ policies/safety_information.cfm.
  • Page 26 SUPERSERVER 1028TP-DC1(R/TR/FR) User's Manual Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut.
  • Page 27 Chapter 4: Warning Statements for AC Systems ‫جسذٌة‬ ‫اصابة‬ ً‫تتسبب ف‬ ‫حالة ٌوكي أى‬ ً‫اًك ف‬ ‫خطز‬ ًٌ‫ٌع‬ ‫هذا الزهز‬ !‫تحذٌز‬ ‫الذوائز‬ ‫بالوخاطز الٌاجوة عي‬ ‫ي على علن‬ ، ‫ك‬ ‫هعذات‬ ‫تعول على أي‬ ‫قبل أى‬ ‫الكهزبائٍة‬ ‫حىادث‬ ‫أي‬ ‫وقىع‬ ‫وٌع‬...

  • Page 28: Installation Instructions

    SUPERSERVER 1028TP-DC1(R/TR/FR) User's Manual Installation Instructions Warning! Read the installation instructions before connecting the system to the power source. 設置手順書 システムを電源に接続する前に、 設置手順書をお読み下さい。 警告 将此系统连接电源前,请先阅读安装说明。 警告 將系統與電源連接前，請先閱讀安裝說明。 Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación.

  • Page 29: Circuit Breaker

    Chapter 4: Warning Statements for AC Systems Circuit Breaker Warning! This product relies on the building's installation for short-circuit (overcurrent) protection. Ensure that the protective device is rated not greater than: 250 V, 20 A. サーキッ ト ・ ブレーカー この製品は、 短絡 （過電流） 保護装置がある建物での設置を前提としています。 保護装置の定格が250 V、...

  • Page 30: Power Disconnection Warning

    SUPERSERVER 1028TP-DC1(R/TR/FR) User's Manual 경고! 이 제품은 전원의 단락(과전류)방지에 대해서 전적으로 건물의 관련 설비에 의존합니다. 보호장치의 정격이 반드시 250V(볼트), 20A(암페어)를 초과하지 않도록 해야 합니다. Waarschuwing Dit product is afhankelijk van de kortsluitbeveiliging (overspanning) van uw electrische installatie. Controleer of het beveiligde aparaat niet groter gedimensioneerd is dan 220V, 20A.
  • Page 31 Chapter 4: Warning Statements for AC Systems ¡Advertencia! El sistema debe ser disconnected de todas las fuentes de energía y del cable eléctrico quitado de los módulos de fuente de alimentación antes de tener acceso el interior del chasis para instalar o para quitar componentes de sistema. Attention Le système doit être débranché...

  • Page 32: Equipment Installation

    SUPERSERVER 1028TP-DC1(R/TR/FR) User's Manual Equipment Installation Warning! Only trained and qualified personnel should be allowed to install, replace, or service this equipment. 機器の設置 トレーニングを受け認定された人だけがこの装置の設置、 交換、 またはサービスを許可 されています。 警告 只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。 警告 只有經過受訓且具資格人員才可安裝、更換與維修此設備。 Warnung Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem, qualifiziertem Personal gestattet werden.

  • Page 33: Restricted Area

    Chapter 4: Warning Statements for AC Systems Waarschuwing Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door geschoold en gekwalificeerd personeel. Restricted Area Warning! This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security.

  • Page 34: Battery Handling

    SUPERSERVER 1028TP-DC1(R/TR/FR) User's Manual ‫אזור עם גישה מוגבלת‬ !‫אזהרה‬ ‫יש להתקין את היחידה באזורים שיש בהם הגבלת גישה. הגישה ניתנת בעזרת‬ .)'‫כלי אבטחה בלבד (מפתח, מנעול וכד‬ ‫محظورة‬ ‫مناطق‬ ٍ‫نتركُبها ف‬ ‫هذه انىحذة‬ ‫تخصيص‬ ‫تم‬ ،‫أداة خاصت‬ ‫من خالل استخذاو‬...
  • Page 35 Chapter 4: Warning Statements for AC Systems Warnung Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers. Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant.

  • Page 36: Redundant Power Supplies (If Applicable To Your System)

    SUPERSERVER 1028TP-DC1(R/TR/FR) User's Manual Redundant Power Supplies (if applicable to your system) Warning! This unit might have more than one power supply connection. All connections must be removed to de-energize the unit. 冗長電源装置 このユニッ トは複数の電源装置が接続されている場合があります。 ユニッ トの電源を切るためには、 すべての接続を取り外さなければなりません。 警告 此部件连接的电源可能不止一个，必须将所有电源断开才能停止给该部件供电。...

  • Page 37: Backplane Voltage (If Applicable To Your System)

    Chapter 4: Warning Statements for AC Systems ‫امداد الطاقة‬ ‫بوحدات‬ ‫عدة اتصاالت‬ ‫جهاز‬ ‫ال‬ ‫يكون لهذا‬ ‫قد‬ ‫الكهرباء‬ ‫عن‬ ‫وحدة‬ ‫ال‬ ‫لعسل‬ ‫كافة االتصاالت‬ ‫يجب إزالة‬ 경고! 이 장치에는 한 개 이상의 전원 공급 단자가 연결되어 있을 수 있습니다. 이 장치에...

  • Page 38: Comply With Local And National Electrical Codes

    SUPERSERVER 1028TP-DC1(R/TR/FR) User's Manual ‫מתח בפנל האחורי‬ !‫הרה‬ ‫אז‬ ‫קיימת סכנת מתח בפנל האחורי בזמן תפעול המערכת. יש להיזהר במהלך‬ .‫העבודה‬ ‫اللىحة‬ ‫أوالطاقة المىجىدة على‬ ‫التيار الكهزبائي‬ ‫مه‬ ‫خطز‬ ‫هناك‬ ‫هذا الجهاس‬ ‫خدمة‬ ‫كه حذرا عند‬ ‫يعمل‬ ‫النظام‬ ‫عندما يكىن‬...

  • Page 39: Product Disposal

    Chapter 4: Warning Statements for AC Systems Attention L'équipement doit être installé conformément aux normes électriques nationales et locales. ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ ‫הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫התקנת‬ ‫المتعلقة‬ ‫المحلية والىطىية‬ ‫قىاويه‬ ‫يجب أن يمتثل لل‬ ‫الكهربائية‬...

  • Page 40: Hot Swap Fan Warning (If Applicable To Your System)

    SUPERSERVER 1028TP-DC1(R/TR/FR) User's Manual ¡Advertencia! Al deshacerse por completo de este producto debe seguir todas las leyes y reglamentos nacionales. Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent.
  • Page 41 Chapter 4: Warning Statements for AC Systems 警告 當您從機架移除風扇裝置，風扇可能仍在轉動。小心不要將手指、螺絲起子和其他 物品太靠近風扇。 Warnung Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt. ¡Advertencia! Los ventiladores podran dar vuelta cuando usted quite ell montaje del ventilador del chasis.

  • Page 42: Power Cable And Ac Adapter

    Electrical Appliance and Material Safety Law prohibits the use of UL or CSA -certified cables (that have UL/CSA shown on the code) for any other electrical devices than products designated by Supermicro only. 電源コードとACアダプター 製品を設置する場合、 提供または指定された接続ケーブル、 電源コードとACアダプター...
  • Page 43 Appareils électroménagers et de loi sur la sécurité Matériel interdit l'utilisation de UL ou CSA câbles certifiés qui ont UL ou CSA indiqué sur le code pour tous les autres appareils électriques que les produits désignés par Supermicro seulement.
  • Page 44 SUPERSERVER 1028TP-DC1(R/TR/FR) User's Manual Notes 4-20...

  • Page 45: Chapter 5 Advanced Motherboard Setup

    Chapter 5: Advanced Serverboard Setup Chapter 5 Advanced Motherboard Setup This chapter covers the steps required to install the X10DRT-(P/PT/PIBF) motherboard into the chassis, connect the data and power cables and install add-on cards. All motherboard jumpers and connections are also described. A layout and quick reference chart are included in this chapter for your reference.

  • Page 46: Connecting Cables

    SUPERSERVER 1028TP-DC1(R/TR/FR) User's Manual Connecting Cables Now that the processors are installed, the next step is to connect the cables to the motherboard. Connecting Data Cables The cables used to transfer data from the peripheral devices have been carefully routed in preconfigured systems to prevent them from blocking the flow of cooling air that moves through the system from front to back.

  • Page 47: Rear I/O Ports

    Chapter 5: Advanced Serverboard Setup Rear I/O Ports See Figure 5-1 below for the and locations of the various rear I/O ports and the UID switch. Figure 5-1. Rear I/O Ports Rear I/O Port Locations and Definitions Dedicated IPMI LAN Back Panel USB 3.0 Port 1 Back Panel USB 3.0 Port 0 Gigabit LAN 2...

  • Page 48: Processor And Heatsink Installation

    • Install the processor into the CPU socket before installing the heatsink. • Refer to the Supermicro website for updates on CPU support. Installing a CPU 1. There are two levers on the LGA 2011 socket. First press and release the load lever labeled "Open 1st".
  • Page 49 Chapter 5: Advanced Serverboard Setup 3. W ith the sec ond lever f ully Open the load plate. retracted, gently push down on the "Open 1st" lever to loosen the load plate. Lift the load plate with your fingers to open it completely. 4.
  • Page 50 SUPERSERVER 1028TP-DC1(R/TR/FR) User's Manual Gently close the load plate. 7. With the "Close 1st" lever fully retracted, gently close the load plate. Push down and lock the lever labeled "Close 1st". 8. Make sure the locking mechanism on the "Close 1st" lever catches the lip of the load plate.

  • Page 51: Installing A Passive Cpu Heatsink

    Chapter 5: Advanced Serverboard Setup Installing a Passive CPU Heatsink Use SNK-P0047PSM on CPU1 and SNK-P0057PS on CPU2. Note: Do not apply any thermal grease to the heatsink or the CPU die--the required amount has already been applied. 1. Place the heatsink on top of the CPU so that the four mounting holes are aligned with those on the motherboard and the heatsink bracket underneath.

  • Page 52: Removing The Heatsink

    SUPERSERVER 1028TP-DC1(R/TR/FR) User's Manual Removing the Heatsink Caution: We do not recommend that the CPU or the heatsink be removed. However, if you do need to uninstall the heatsink, please follow the instructions below to prevent damage to the CPU or the CPU socket.

  • Page 53: Installing Memory

    The X10DRT-(P/PT/PIBF) has sixteen DIMM slots supporting up to 2 TB of LRDIMM (Load Reduced DIMM) or 512 GB of RDIMM (Registered DIMM) DDR4- 2400/2133/1866/1600 MHz registered ECC memory. Note: Check the Supermicro website (www.supermicro.com) for the latest memory support information. Release Tab...

  • Page 54: Dimm Slots

    SUPERSERVER 1028TP-DC1(R/TR/FR) User's Manual Processor & Memory Module Population Configuration For the memory to work properly, follow the tables below when populating the DIMM slots. Processors and their Corresponding Memory Modules Corresponding DIMMs CPU# CPU 1 DIMMA1 DIMMB1 DIMMC1 DIMMD1...
  • Page 55 Chapter 5: Advanced Serverboard Setup Populating DDR4 RDIMM/LRDIMM ECC Memory Modules Populating RDIMM/LRDIMM DDR4 Memory Modules Speed (MT/s); Voltage (V); Slots per Channel (SPC) and DIMMs per Channel (DPC) Ranks DIMM Capacity 2 Slots per Channel Per DIMM (GB) Type 1 DPC 2 DPC and Data...

  • Page 56: Motherboard Details

    SUPERSERVER 1028TP-DC1(R/TR/FR) User's Manual Motherboard Details LAN1/LAN2 USB0/1 (3.0) IB_LINK_LED1 IPMI_LAN BIOS Slot2 Slot1 QSFP LAN CTRL 10G/1G JTPM1 CPLD JBT1 BATTERY SXB1 CPU2_VRM_HS1 CPU2 X10DRT-P Series Rev. 1.02 SXB2 CPU1 Figure 5-4. X10DRT-(P/PT/PIBF) Motherboard Layout (not drawn to scale) Notes •...

  • Page 57: X10Drt-(P/Pt/Pibf) Motherboard Quick Reference

    Connector Description COM1 COM Port 1 FAN3/FAN4 System Fan Headers Supermicro Proprietary Slot for Add-On Card for Power, Front Control Panel JIPMB1 4-pin External BMC I C Header (for an IPMI Card) JSD1 SATA DOM (Device On Module) Power Connector...

  • Page 58: Connector Definitions

    SUPERSERVER 1028TP-DC1(R/TR/FR) User's Manual Connector Definitions Main Power Main power to the motherboard is supplied through the system backplane (BPN- ADP-3108L-H6IR), which receives power directly from the power supply. One hard drive backplane in each node (BPN-ADP-S3008H-L6iP) plugs into system...
  • Page 59 Chapter 5: Advanced Serverboard Setup Fan Headers Fan Header Pin Definitions This motherboard has two system fan Pin# Definition headers (Fan 3/Fan 4). These 4-pin Ground fans headers are backward compatible +12V with traditional 3-pin fans. However, fan Tachometer speed control is available for 4-pin fans PWR Modulation only.

  • Page 60: Jumper Settings

    SUPERSERVER 1028TP-DC1(R/TR/FR) User's Manual Jumper Settings Connector Pins Explanation of Jumpers To modify the operation of the motherboard, Jumper jumpers can be used to choose between optional settings. Jumpers create shorts between two pins to change the function Setting of the connector. Pin 1 is identified with a square solder pad on the printed circuit board.
  • Page 61 Chapter 5: Advanced Serverboard Setup Watch Dog Enable/Disable Watch Dog (JWD1) is a system monitor Watch Dog that can reboot the system when a Jumper Settings software application hangs. Close pins Jumper Setting Definition 1-2 to reset the system if an application Pins 1-2 Reset hangs.

  • Page 62: Onboard Indicators

    SUPERSERVER 1028TP-DC1(R/TR/FR) User's Manual Onboard Indicators LAN 1/2 Link LED Activity LED LAN1/2 Port LEDs The Ethernet ports on the rear I/O panel have two indicators. On each port, the LED on the right indicates activity by LAN Link Indicator LED blinking amber.

  • Page 63: 5-10 Pci-Express And Sata Connections

    Chapter 5: Advanced Serverboard Setup BMC Heartbeat LED BMC Heartbeat LED Status A BMC Heartbeat LED is provided to Color/State Definition display BMC status. When blinking, Green: Blinking BMC:Normal BMC is functioning normally. See the table at right for more information. InfiniBand LED Indicators InfiniBand Link LED (Green) Status...

  • Page 64: 5-11 Installing Software

    SUPERSERVER 1028TP-DC1(R/TR/FR) User's Manual 5-11 Installing Software The Supermicro ftp site contains drivers and utilities for your system at ftp://ftp. supermicro.com. Some of these must be installed, such as the chipset driver. After accessing the ftp site, go into the CDR_Images directory and locate the ISO file for your motherboard.

  • Page 65: Superdoctor® 5

    Chapter 5: Advanced Serverboard Setup SuperDoctor® 5 The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface in Windows and Linux operating systems. The program monitors system health information such as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 66: 5-12 Onboard Battery

    SUPERSERVER 1028TP-DC1(R/TR/FR) User's Manual 5-12 Onboard Battery Please handle used batteries carefully. Do not damage the battery in any way; a damaged battery may release hazardous materials into the environment. Do not discard a used battery in the garbage or a public landfill. Please comply with the regulations set up by your local hazardous waste management agency to dispose of your used battery properly.

  • Page 67: Chapter 6 Chassis Setup And Maintenance

    Chapter 6: Chassis Setup and Maintenance Chapter 6 Chassis Setup and Maintenance Overview This chapter covers the steps required to install components and perform maintenance on the chassis. The only tool required is a Phillips screwdriver. Review the warnings and precautions listed in the manual before setting up or servicing this chassis.

  • Page 68: Removing Power From The System

    SUPERSERVER 1028TP-DC1(R/TR/FR) User's Manual Removing Power from the System Before performing some setup or maintenance tasks, use the following procedure to ensure that power has been removed from the system. 1. Use the operating system to power down the nodes, following the on-screen prompts.
  • Page 69 Chapter 6: Chassis Setup and Maintenance 2. Lift the latch, pulling up and toward the chassis front. Latch Figure 6-4. Pulling the Cover Latch Figure 6-5. Cover Open Caution: Except for short periods of time, do not operate the server without the cover in place.

  • Page 70: Installing Hard Drives

    These carriers also help to promote proper airflow for the drive bays. For this reason, even carriers without drives must remain in the chassis. Enterprise level hard disk drives are recommended for use in Supermicro chassis and servers. Refer to a list at, http://www.supermicro.com/products/nfo/files/storage/ SBB-HDDCompList.pdf.
  • Page 71 Chapter 6: Chassis Setup and Maintenance Dummy Drive Drive Carrier Figure 6-7. Removing a Dummy Drive from Carrier Installing a Drive into the Carrier 1. Remove the dummy drive from the carrier by removing four screws. 2. Install a new drive into the carrier with the printed circuit board side facing down so that the mounting holes in the drive align with those in the carrier.
  • Page 72 SUPERSERVER 1028TP-DC1(R/TR/FR) User's Manual 3. Secure the hard drive into the carrier with the screws. 4. Open the drive carrier handle and use it push the carrier assembly into the chassis. 5. Gently close the drive carrier handle to secure the drive and carrier into the chassis drive bay.

  • Page 73: Expansion Cards

    Chapter 6: Chassis Setup and Maintenance Expansion Cards Each node drawer includes a slot for one low profile, half length PCI-Express expansion card. Installing a PCI Expansion Card 1. Power down the node and remove the drawer. 2. Remove the riser card and riser card bracket from the drawer. 3.

  • Page 74: Installing The Air Shroud

    SUPERSERVER 1028TP-DC1(R/TR/FR) User's Manual Installing the Air Shroud Air shrouds concentrate airflow to maximize fan effectiveness. Figure 6-10. Air Shroud Installation Installing an Air Shroud 1. Remove the node tray from the chassis. 2. Place the air shroud in the tray as shown.

  • Page 75: System Fans

    Chapter 6: Chassis Setup and Maintenance System Fans Six hot-swappable fans provide cooling from the middle of the chassis. Figure 6-11. Replacing a Fan Replacing a System Fan 1. Use IPMI or another monitoring tool, if available, to determine which fan has failed.

  • Page 76: Checking The Server Air Flow

    SUPERSERVER 1028TP-DC1(R/TR/FR) User's Manual Checking the Server Air Flow Checking the Air Flow • Make sure there are no objects to obstruct airflow in and out of the server. In addition, if you are using a front bezel, make sure the bezel's filter is replaced periodically.

  • Page 77: Power Supply

    The chassis features redundant power supplies. They are hot-swappable, meaning they can be changed without powering down the system. New units can be ordered directly from Supermicro or authorized distributors. These power supplies are auto-switching capable. This feature enables them to automatically sense the input voltage and operate at a 100-120v or 180-240v.
  • Page 78 SUPERSERVER 1028TP-DC1(R/TR/FR) User's Manual Changing the Power Supply: 1. Unplug the AC cord from the module to be replaced. 2. Push the release tab on the back of the power supply as illustrated. Release Tab Figure 6-12. Power Supply Release Tab 3.

  • Page 79: Chapter 7 Bios

    When an option is selected in the left frame, it is highlighted in white. Often a text message will accompany it. Note: the AMI BIOS has default text messages built in. Supermicro retains the option to include, omit, or change any of these text messages.

  • Page 80: How To Start The Setup Utility

    Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update. If you have to update the BIOS, do not shut down or reset the system while the BIOS is updating to avoid possible boot failure.
  • Page 81 Day MM/DD/YYYY format. The time is entered in HH:MM:SS format. Note: The time is in the 24-hour format. For example, 5:30 P.M. appears as 17:30:00. Supermicro X10DRT-P Series BIOS Version: This item displays the version of the BIOS ROM used in the system.

  • Page 82: Advanced Setup Configurations

    SUPERSERVER 1028TP-DC1(R/TR/FR) USER'S MANUAL Advanced Setup Configurations Use the arrow keys to select Advanced setup and press <Enter> to access the submenu items: Warning: Take Caution when changing the Advanced settings. An incorrect value, a very high DRAM frequency or an incorrect BIOS timing setting may cause the system to malfunction.

  • Page 83: Power Configuration

    Chapter 7: BIOS Wait For 'F1' If Error Select Enabled to force the system to wait until the 'F1' key is pressed if an error occurs. The options are Disabled and Enabled. INT19 (Interrupt 19) Trap Response Interrupt 19 is the software interrupt that handles the boot disk function. When this item is set to Immediate, the ROM BIOS of the host adaptors will "capture"...

  • Page 84: Cpu Configuration

    SUPERSERVER 1028TP-DC1(R/TR/FR) USER'S MANUAL CPU Configuration  This submenu displays the following CPU information as detected by the BIOS. It also allows the user to configure CPU settings. • Processor Socket • Processor ID • Processor Frequency • Processor Max Ratio •...
  • Page 85 Chapter 7: BIOS Hardware Prefetcher (Available when supported by the CPU) If set to Enable, the hardware prefetcher will prefetch streams of data and instruc- tions from the main memory to the L2 cache to improve CPU performance. The options are Disable and Enable. Adjacent Cache Line Prefetch (Available when supported by the CPU) Select Enable for the CPU to prefetch both cache lines for 128 bytes as comprised.

  • Page 86: Advanced Power Management Configuration

    SUPERSERVER 1028TP-DC1(R/TR/FR) USER'S MANUAL X2 APIC (Advanced Programmable Interrupt Controller) Based on Intel's Hyper-Threading architecture, each logical processor (thread) is assigned 256 APIC IDs (APIDs) in 8-bit bandwidth. When this feature is set to En- able, the APIC ID will be expanded (X2) from 8 bits to 16 bits to provide 512 APIDs to each thread to enhance CPU performance.
  • Page 87 Chapter 7: BIOS P-state Coordination This feature is used to change the P-state (Power-Performance State) coordi- nation type. P-state is also known as "SpeedStep" for Intel processors. Select HW_ALL to change the P-state coordination type for hardware components only. Select SW_ALL to change the P-state coordination type for all software installed in the system.

  • Page 88: Chipset Configuration

    SUPERSERVER 1028TP-DC1(R/TR/FR) USER'S MANUAL Chipset Configuration Warning! Please set the correct settings for the items below. A wrong configuration setting may cause the system to become malfunction. North Bridge This feature allows the user to configure the settings for the Intel North Bridge.
  • Page 89 Chapter 7: BIOS IOU0 (II0 PCIe Port 2) This item configures the PCI-E port Bifuraction setting for a PCI-E port specified by the user. The options are x4x4x4x4, x4x4x8, x8x4x4, x8x8, x16, and Auto. PORT 2A Link Speed This item configures the link speed of a PCI-E port specified by the user. The options are Gen 1 (Generation 1) (2.5 GT/s), Gen 2 (Generation 2) (5 GT/s), and Gen 3 (Generation 3) (8 GT/s).
  • Page 90 SUPERSERVER 1028TP-DC1(R/TR/FR) USER'S MANUAL  Intel VT for Directed I/O (VT-d) Intel VT for Direct I/O (VT-d) Intel VT for Directed I/O (VT-d) ® Select Enable to use Intel Virtualization Technology support for Direct I/O VT-d support by reporting the I/O device assignments to the VMM (Virtual Machine Monitor) through the DMAR ACPI tables.

  • Page 91: Memory Configuration

    Chapter 7: BIOS Link Speed Mode Use this item to select the data transfer speed for QPI Link connections. The options are Fast and Slow. Link Frequency Select Use this item to select the desired frequency for QPI Link connections. The op- tions are 6.4GB/s, 8.0GB/s, 9.6GB/s, Auto, and Auto Limited.

  • Page 92: Dimm Information

    SUPERSERVER 1028TP-DC1(R/TR/FR) USER'S MANUAL Data Scrambling Select Enabled to enable data scrambling to enhance system performance and data integrity. The options are Auto, Disabled and Enabled. DRAM RAPL (Running Average Power Limit) Baseline Use this feature to set the run-time power-limit baseline for DRAM modules. The options are Disable, DRAM RAPL Mode 0, and DRAM RAPL Mode 1.
  • Page 93 Chapter 7: BIOS the same set of operations in parallel to boost performance. The options are Disable, Mirror, and Lockstep Mode. Lockstep x4 DIMMs Select Enable to enable Lockstep support for x4 DIMM modules. The options are Auto, Disabled, and Enabled. Memory Rank Sparing Select Enable to enable memory-sparing support for memory ranks to improve memory performance.

  • Page 94: South Bridge

    SUPERSERVER 1028TP-DC1(R/TR/FR) USER'S MANUAL South Bridge  The following South Bridge information will display: USB Configuration  • USB Module Version • USB Devices Legacy USB Support Select Enabled to support onboard legacy USB devices. Select Auto to disable legacy support if there are no legacy USB devices present. Select Disabled to have all USB devices available for EFI applications only.
  • Page 95 Chapter 7: BIOS EHCI2 Select Enabled to enable EHCI (Enhanced Host Controller Interface) support on USB 2.0 connector #2 (-at least one USB 2.0 connector should be enabled for EHCI support.) The options are Disabled and Enabled. XHCI Pre-Boot Drive Select Enabled to enable XHCI (Extensible Host Controller Interface) support on a pre-boot drive specified by the user.

  • Page 96: Sata Configuration

    SUPERSERVER 1028TP-DC1(R/TR/FR) USER'S MANUAL SATA Configuration  When this submenu is selected, AMI BIOS automatically detects the presence of the SATA devices that are supported by the Intel PCH chip and displays the fol- lowing items: SATA Controller This item enables or disables the onboard SATA controller supported by the Intel PCH chip.
  • Page 97 Chapter 7: BIOS Port 0 ~ Port 5 SATA Device Type Use this item to specify if the SATA port specified by the user should be con- nected to a Solid State drive or a Hard Disk Drive. The options are Hard Disk Drive and Solid State Drive.
  • Page 98 SUPERSERVER 1028TP-DC1(R/TR/FR) USER'S MANUAL Port 0 ~ Port 5 Hot Plug Select Enabled to enable hot-plugging support for a port specified by the user, which will allow the user to replace a SATA disk drive installed on this port without shutting down the system.
  • Page 99 Chapter 7: BIOS • Software Preserve Support sSATA Port 0~ Port 3 Select Enabled to enable an sSATA port specified by the user. The options are Disabled and Enabled. sSATA Port 0 ~ Port 3 Hot Plug Select Enabled to enable hot-plugging support for a port specified by the user, which will allow the user to replace a sSATA disk drive installed on this port without shutting down the system.
  • Page 100 SUPERSERVER 1028TP-DC1(R/TR/FR) USER'S MANUAL sSATA RAID Option ROM/UEFI Driver Select EFI to load the EFI driver for system boot. Select Legacy to load a legacy driver for system boot. The options are Disabled, EFI, and Legacy. sSATA Port 0~ Port 3 This item displays the information detected on the installed sSATA drives on the particular sSATA port.
  • Page 101 Chapter 7: BIOS • ME Firmware Status #2 • Current State • Error Code PCIe/PCI/PnP Configuration The following PCI information will be displayed: • PCI Bus Driver Version • PCI Device Common Settings PCI Latency Timer Use this item to configure the PCI latency timer for a device installed on a PCI bus. Select 32 to set the PCI latency timer to 32 PCI clock cycles.
  • Page 102 SUPERSERVER 1028TP-DC1(R/TR/FR) USER'S MANUAL Maximum Read Request Select Auto for the system BIOS to automatically set the maximum size for a read request for a PCI-E device to enhance system performance. The options are Auto, 128 Bytes, 256 Bytes, 512 Bytes, 1024 Bytes, 2048 Bytes, and 4096 Bytes.

  • Page 103: Super Io Configuration

    Chapter 7: BIOS Network Stack Select Enabled to enable PXE (Preboot Execution Environment) or UEFI (Uni- fied Extensible Firmware Interface) for network stack support. The options are Enabled and Disabled. Super IO Configuration  Super IO Chip AST2400 Serial Port 1 Configuration/Serial Port 2 Configuration ...
  • Page 104 SUPERSERVER 1028TP-DC1(R/TR/FR) USER'S MANUAL *If the item above set to Enabled, the following items will become available for configuration: COM1 Console Redirection Settings Terminal Type This feature allows the user to select the target terminal emulation type for Con- sole Redirection. Select VT100 to use the ASCII Character set. Select VT100+ to add color and function key support.
  • Page 105 Chapter 7: BIOS VT-UTF8 Combo Key Support Select Enabled to enable VT-UTF8 Combination Key support for ANSI/VT100 terminals. The options are Enabled and Disabled. Recorder Mode Select Enabled to capture the data displayed on a terminal and send it as text messages to a remote server.
  • Page 106 SUPERSERVER 1028TP-DC1(R/TR/FR) USER'S MANUAL SOL/COM2 Console Redirection Settings Use this feature to specify how the host computer will exchange data with the client computer, which is the remote computer used by the user. Terminal Type Use this feature to select the target terminal emulation type for Console Redirec- tion.
  • Page 107 Chapter 7: BIOS VT-UTF8 Combo Key Support Select Enabled to enable VT-UTF8 Combination Key support for ANSI/VT100 terminals. The options are Enabled and Disabled. Recorder Mode Select Enabled to capture the data displayed on a terminal and send it as text messages to a remote server.
  • Page 108 SUPERSERVER 1028TP-DC1(R/TR/FR) USER'S MANUAL EMS Console Redirection Settings (Available when EMS Console Redirection is enabled) Use this feature to specify how the host computer will exchange data with the client computer, which is the remote computer used by the user.

  • Page 109: Acpi Settings

    Chapter 7: BIOS port to enhance data integrity and network security. Please reboot the system for a change on this setting to take effect. The options are Enabled and Disabled. TPM State Select Enabled to use TPM (Trusted Platform Module) settings to enhance system data security.

  • Page 110: Event Logs

    SUPERSERVER 1028TP-DC1(R/TR/FR) USER'S MANUAL Event Logs Use this tab page to configure Event Log settings. Change SMBIOS Event Log Settings  This feature allows the user to configure SMBIOS Event settings. Enabling/Disabling Options SMBIOS Event Log Select Enabled to enable SMBIOS (System Management BIOS) Event Logging during system boot.

  • Page 111: View Smbios Event Log

    Chapter 7: BIOS Erasing Settings Erase Event Log Select Yes to erase all error events in the SMBIOS (System Management BIOS) log before an event logging is initialized at bootup. The options are No and Yes. When Log is Full Select Erase Immediately to immediately erase all errors in the SMBIOS event log when the event log is full.

  • Page 112: Ipmi

    SUPERSERVER 1028TP-DC1(R/TR/FR) USER'S MANUAL IPMI Use this feature to configure Intelligent Platform Management Interface (IPMI) settings. BMC (BaseBoard Management Controller) Firmware Revision This item indicates the BMC firmware revision used in your system. IPMI Status This item indicates the status of the IPMI firmware installed in your system.

  • Page 113: Bmc Network Configuration

    Chapter 7: BIOS When SEL is Full This feature allows the user to determine what the AMI BIOS should do when the system event log is full. Select Erase Immediately to erase all events in the log when the system event log is full. The options are Do Nothing and Erase Immediately. Note: After making changes on a setting, be sure to reboot the system for the changes to take effect.

  • Page 114: Security Settings

    SUPERSERVER 1028TP-DC1(R/TR/FR) USER'S MANUAL Security Settings This tab page allows the user to configure the following security settings for the system. Password Check Select Setup for the system to prompt for a password upon entering the BIOS setup utility. Select Always for the system to prompt for a password at bootup and upon entering the BIOS Setup utility.

  • Page 115: Boot Settings

    Chapter 7: BIOS Boot Settings Use this tab page to configure Boot Settings: Boot Configuration Setup Prompt Timeout Use this item to indicate how many seconds the system shall wait for the BIOS setup activation key to respond before the system starts to boot. The default setting is 1. Boot Mode Select Use this item to select the type of device to be used for system boot.
  • Page 116 SUPERSERVER 1028TP-DC1(R/TR/FR) USER'S MANUAL • Dual Boot Order #7 • Dual Boot Order #8 • Dual Boot Order #9 • Dual Boot Order #10 • Dual Boot Order #11 • Dual Boot Order #12 • Dual Boot Order #13 •...

  • Page 117: Save & Exit

    Chapter 7: BIOS Save & Exit Select the Save & Exit tab from the BIOS setup screen to configure the settings below. Discard Changes and Exit Select this option to quit the BIOS setup without making any permanent changes to the system configuration, and reboot the computer. Select Discard Changes and Exit from the Exit menu and press <Enter>.
  • Page 118 SUPERSERVER 1028TP-DC1(R/TR/FR) USER'S MANUAL Restore Defaults Select this item and press <Enter> to load the manufacture default settings which are designed for maximum system performance but not for maximum stability. Save As User Defaults Select this item and press <Enter> to save the current BIOS settings as user's default settings for future use.

  • Page 119: Appendix A Bios Error Beep Codes

    Appendix A: BIOS Error Beep Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed at each system boot, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue to boot.
  • Page 120 SuperServer 1028TP-DC1(R/TR/FR) User's Manual Notes...

  • Page 121: Appendix B Uefi Bios Recovery Instructions

    Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update. If you need to update the BIOS, do not shut down or reset the system while the BIOS is updating to avoid possible boot failure.
  • Page 122 Root "\" Directory of a USB device or a writeable CD/DVD. Note: If you cannot locate the "Super.ROM" file in your driver disk, visit our website at www.supermicro.com to download the BIOS image into a USB flash device and rename it "Super.ROM" for BIOS recovery use.
  • Page 123 Appendix B: System Specifications 4. After locating the new BIOS binary image, the system will enter the BIOS Recovery menu as shown below. Note: At this point, you may decide if you want to start with BIOS recovery. If you decide to proceed with BIOS recovery, follow the procedures below. 5.
  • Page 124 UPER ERVER 1028TP-DC1(R/TR/FR) User's Manual 6. After the process of BIOS recovery is completed, press any key to reboot the system. 7. Using a different system, extract the BIOS package into a bootable USB flash drive. 8. When a DOS prompt appears, enter FLASH.BAT BIOSname.### at the prompt. Note: Do not interrupt this process until BIOS flashing is completed.

  • Page 125: Appendix C System Specifications

    Note: heck the Supermicro website (www. See the memory section in Chapter 5 for details. C supermicro.com) for the latest memory support information. LSI 3108 controller to support four SAS3 hard drives per node SATA Serial ATA controller integrated into the Intel PCH C612 to provide four SATA3...

  • Page 126: System Cooling

    UPER ERVER 1028TP-DC1(R/TR/FR) User's Manual Expansion Slots One low-profile PCI-E expansion card per node Motherboard X10DRT-(P/PT/PIBF) serverboard (proprietary form factor) Dimensions: (LxW) 6.8 x 16.64 in. (172.72 x 422.66 mm) Chassis SC809H--R1K05 (1U rackmount) Dimensions: (WxHxD) 17.2 x 1.75 x 28.25 in. (437 x 45 x 718 mm) Weight Gross Weight: 48.1 lbs (21.9 kg) Net Weight: 33.5 lbs (15.2 kg)

  • Page 127: Regulatory Compliance

    Appendix C: System Specifications Note 1: When operating in the expanded temperature range, system performance is equivalent to the normal operating temperature range. Note 2: When operating in the expanded temperature range, select a CPU for which the TDP is between 85 W to 145 W. Do not use frequency optimized SKUs, E5-2667 v3, E5-2643 v3, E5-2637 v3, and E5-2623 v3.
  • Page 128 ERVER 1028TP-DC1(R/TR/FR) User's Manual (continued from front) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency com- munication devices or other critical systems whose failure to perform be reasonably expected to result in significant injury or loss of life or catastrophic property damage.

Table of Contents

Save PDF
