Page 1 SuperServer ® ARS-121L-DNR-LCC USER’S MANUAL Revision 1.0...
Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
Page 3 If you have any questions, please contact our support team at: support@supermicro.com This manual may be periodically updated without notice. Please check the Supermicro website for possible updates to the manual revision level. Secure Data Deletion A secure data deletion tool designed to fully erase all data from storage devices can be found on our website: https://www.supermicro.com/about/policies/disclaimer.cfm?url=/wdl/utility/...
Page 4 Preface Contents Contacting Supermicro ......................7 Chapter 1 Introduction 1.1 Overview ..........................8 1.2 System Features ........................9 Front View ...........................9 Drive Carrier Indicators ....................10 Control Panel ........................11 Rear View ..........................12 Power Supply Status Indicator ..................13 Top View ..........................14 1.3 Motherboard Layout ......................15 Quick Reference Table ......................16...
Page 5 Preface 2.3 Installing the System into a Rack..................22 Separating the Sections of the Rack Rails ...............22 Releasing the Inner Rail....................23 Installing the Inner Rails on the Chassis .................24 Installing the Outer Rails on the Rack ................25 Installing into the Rack ......................26 Removing the Chassis from the Rack ................27 Removing the Outer Rails from the Rack .................28 Chapter 3 Maintenance and Component Installation...
Page 6 7.7 Reporting an Issue ......................124 Technical Support Procedures ..................124 Returning Merchandise for Service .................125 Vendor Support Filing System ..................125 7.8 Feedback ...........................125 7.9 Contacting Supermicro .....................126 Chapter 8 BIOS 8.1 Introduction ........................127 8.2 Main Setup ........................128 8.3 Advanced ..........................130 8.4 BMC ..........................174 8.5 Security ..........................180...
Page 7 San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) Sales-USA@supermicro.com (Sales Inquiries) Government_Sales-USA@supermicro.com (Gov. Sales Inquiries) support@supermicro.com (Technical Support) RMA@supermicro.com (RMA Support) Webmaster@supermicro.com (Webmaster) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.
Page 8 1U rackmount, 1.75" x 17.33" x 37" (44 x 440 x 940 mm) (H x W x D) Notes: A Quick Reference Guide can be found on the product page of the Supermicro website. The following safety models associated with the ARS-121L-DNR-LCC has been certified as compliant with UL or CSA: MG102-R20G1 and MG102-GH200.
Page 9 Chapter 1: Introduction 1.2 System Features The following views of the system display the main features. Refer to Appendix B for additional specifications. Front View Control Module Control Panel E1.S SSD Figure 1-1. Front View System Features: Front Feature Description Control Panel One control pad with power switch and LED indicators E1.S SSD (per node)
Page 10 Chapter 1: Introduction Drive Carrier Indicators Each E1.S NVMe SSD drive has two LED indicators: an activity indicator and a status indicator. Drive Carrier LED Indicators Color Blinking Pattern Behavior for Device Green Solid On Idle Activity LED Green Blinking I/O activity Eject device Idle...
Page 11 Chapter 1: Introduction Control Panel The switches and LEDs located on the control panel are described below. Power LED NIC2 LED Power Fail LED Power Button Information LED Storage Drive LED NIC1 LED Figure 1-2. Control Panel Control Panel Features Feature Description The main power button is used to apply or remove power from the power supply to the...
Page 12 Chapter 1: Introduction Rear View The illustration below shows the features included on the rear of the chassis. Power supply modules include a power supply LED. Liquid Cooling Tubes Mini DisplayPort PCIe Slots USB Port Power Supply Modules IPMI LAN Port Figure 1-3.
Page 13 Indicates that the power supply has a warning condition and continues to operate. Indicates that the power supply is plugged in, and is in an abnormal state. Solid Amber The system might need service. Please contact Supermicro technical support. No AC power to modules...
Page 14 Chapter 1: Introduction Top View Drive Bays CPUs Cold Plates Fans PCIe Slots Power Supplies Figure 1-4. System: Top View System Features: Top Feature Description Dual processors Processors (per node) One NVIDIA Dual 72-core CPUs on a Grace CPU Superchip Drive Bays (per node) Supports two E1.S NVMe drives Fans...
Page 15 Chapter 1: Introduction 1.3 Motherboard Layout Below is a layout of the G1SMH motherboard with jumper, connector, and LED locations shown. See the table on the following page for descriptions. For detailed descriptions, pinout information, and jumper settings, refer to Chapter 4 or the Motherboard...
Page 16 Chapter 1: Introduction Quick Reference Table Description Status ACT_LED1 M.2 Activity Green Blinking: M.2 is active ACT_LED2 M.2 Activity Green Blinking: M.2 is active HB_LED1 CPLD Initialization Green Blinking: CPLD initialized PWR_LED1 Motherboard Power Solid green after pressing PWRBTN1 LED1 EROT Detected Yellow Solid: EROT is detected LED2...
Page 17 Up to eight PCIe Gen5 x16 option to bifurcate Module Thermal Design Power (TDP) 500 W TDP with memory Form Factor Superchip module Grace CPU Superchip Thermal Solution Air cooled Figure 1-6. Grace CPU Supership Better Faster Greener™ © 2023 Supermicro...
Page 18 Chapter 1: Introduction Motherboard Block Diagram Figure 1-6. Motherboard Block Diagram Figure 1-7. Motherboard Block Diagram Note: This is a general block diagram and may not exactly represent the features on your motherboard. See the previous pages for the actual specifications of your motherboard.
Page 19 Chapter 2: Server Installation Chapter 2 Server Installation This chapter provides advice and instructions for mounting your system in a server rack. If your system is not already fully integrated with processors, system memory, etc., refer to Chapter 3 for details on installing those specific components. Caution: Electrostatic Discharge (ESD) can damage electronic components.
Page 20 Chapter 2: Server Installation Rack Precautions • Ensure that the leveling jacks on the bottom of the rack are extended to the floor so that the full weight of the rack rests on them. • In single rack installations, stabilizers should be attached to the rack. In multiple rack in- stallations, the racks should be coupled together.
Page 21 Chapter 2: Server Installation Mechanical Loading Equipment should be mounted into a rack so that a hazardous condition does not arise due to uneven mechanical loading. Circuit Overloading Consideration should be given to the connection of the equipment to the power supply circuitry and the effect that any possible overloading of circuits might have on overcurrent protection and power supply wiring.
Page 22 Chapter 2: Server Installation 2.3 Installing the System into a Rack This section provides information on installing the SC126E32 chassis into a rack unit with the quick-release rails provided. There are a variety of rack units on the market, which may mean the assembly procedure will differ slightly.
Page 23 Chapter 2: Server Installation Releasing the Inner Rail It is necessary to release the inner rail from the middle and outer rails before installing the inner rail on the chassis. Releasing the Inner Rail from the Middle and Outer Rails 1.
Page 24 Chapter 2: Server Installation Installing the Inner Rails on the Chassis Installing the Inner Rails 1. Confirm that the left and right inner rails have been correctly identified. 2. Place the inner rail firmly against the side of the chassis, aligning the pins on the side of the chassis with the slotted through holes in the inner rail.
Page 25 Chapter 2: Server Installation Installing the Outer Rails on the Rack Installing the Outer Rails 1. Confirm that the left and right outer rails have been correctly identified. 2. Release the small locking lever on the inside of the middle rail and push the middle rail back into the outer rail.
Page 26 Chapter 2: Server Installation Installing into the Rack After the rails are installed on the chassis and on the rack, the server can be installed in the rack. It is heavy and requires two to three people to lift. Installing the Chassis into a Rack 1.
Page 27 Chapter 2: Server Installation Removing the Chassis from the Rack Caution: The chassis is heavy and requires two to three people to lift it out. Removing the Chassis 1. Lift the right and left front latches on either side of the front panel. 2.
Page 28 Chapter 2: Server Installation Removing the Outer Rails from the Rack In the uncommon event that it is necessary to remove the outer rails from the rack, follow these instructions. The chassis must be out of the rack. Releasing the Outer Rails 1.
Page 29 Chapter 3: Maintenance and Component Installation Chapter 3 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and/or part numbers given. Installation or replacement of most components require that power first be removed from the system.
Page 30 Chapter 3: Maintenance and Component Installation 3.2 Accessing the System The chassis features a removable top cover for access to the internal components. When performing service on components inside the system, remove the system from the rack and place it on a work bench or desk. Do not service with the system extended from the rack. Removing the Top Cover The top cover can be removed to access the chassis fans while the server continues to operate.
Page 31 • Make sure to install the motherboard into the chassis before you install the heatsink. • Refer to the Supermicro website for updates on the Superchip module support. • Processors and heatsinks must be installed by the manufacturer.
Page 32 Chapter 3: Maintenance and Component Installation Installing the Superchip onto the Motherboard 1. Align the Superchip with its guide pins to the holes circled in red on the motherboard. Superchip Bottom View Superchip Top View Top view...
Page 33 Chapter 3: Maintenance and Component Installation 2. Before the springs underneath the Superchip are compressed, check the alignment of the guide pins and the holes on the motherboard again. 3. Fasten the four screws using a torque of 9.5 +/- 4% in-lbf (11 kgf-cm) to complete the Superchip installation.
Page 34 Chapter 3: Maintenance and Component Installation 4. Place thermal pads on the module. The thermal pads are shown as below. 5. Peel off the thermal pad protector underneath each heatsink. Thermal Interface Materials Size Quantity Gap 285-1036-000 TGP3500PT, 7.0 x 29.0 x 2.0 mm 285-1037-000 TGP3500PT, 6.0 x 17.0 x 2.0 mm 285-1038-000...
Page 35 Chapter 3: Maintenance and Component Installation 6. Place the cold plates on top of the Superchip module. 7. Using a torque of 9.5 +/- 4% in-lbf (11 kgf-cm), secure each cold plate onto the Superchip module with four screws. IN-LBF KGF-CM 6 7 8 9 10 1 1 1...
Page 36 Chapter 3: Maintenance and Component Installation Un-installing the NVIDIA Grace™ CPU Superchip Module and Heatsinks 1. Remove the heatsinks attached to the top of the Superchip by reversing the installation procedure. 2. Remove the screws from the Superchip. 3. Lift the Superchip off from the motherboard. 3.4 Memory The G1SMH supports up to 480 GB of LPDDR5 ECC with 1 TB/s throughput.
Page 37 Chapter 3: Maintenance and Component Installation 3.5 Motherboard Battery The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. Replacing the Battery Begin by removing power from the system.
Page 38 The ARS-121L-DNR-LCC supports a total of up to four E1.S NVMe drives, using mounting trays or carriers (two E1.S NVMe drives per node). Note: Enterprise-level storage modules are recommended for use in Supermicro servers. For information on recommended drives, visit the Supermicro website.
Page 39 Chapter 3: Maintenance and Component Installation Removing PCIe Bays The CSE-MG102TS-R000NDFP-2N chassis provides two PCIe bays per node. The PCIe bay is a pull-out module. Removal of the pull-out module is shown below. Unless this module needs to be serviced, it is seldom removed and is shown here for information purposes. Installing an Expansion Card 1.
Page 40 Chapter 3: Maintenance and Component Installation 3.7 System Cooling Fans Up to seven counter-rotating, heavy-duty fans with optimal fan speed control provide cooling for the system. These fans are not hot-swappable; power must be removed from the system before replacing. Replacing a System Fan 1.
Page 41 The CSE-MG102TS-R000NDFP-2N features two redundant 2000 W CRPS power supplies. Each power supply can be changed without powering down the system. New units can be ordered directly from Supermicro or authorized distributors. These power supplies are auto-switching capable. This feature enables them to automatically sense the input voltage and operate at a 100-120 V or 180-240 V.
Page 42 Chapter 4: Motherboard Connections Chapter 4 Motherboard Connections This section describes the connections on the motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A motherboard layout indicating component locations may be found in Chapter 1.
Page 43 Chapter 4: Motherboard Connections 12 V 8-pin IO Board Power Supply Connector (JPWR6) JPWR6 is an 8-pin ATX power input to provide power to the IO board. Refer to the table below for pin definitions. 12 V 8-pin Power Connector Pin Definitions Pin# Definition...
Page 44 Port 80 connection. Use this header to enhance system performance and data security. Refer to the table below for pin definitions. Please go to the following link for more information on the TPM: http://www.supermicro.com/manuals/other/TPM.pdf. Trusted Platform Module Header Pin Definitions...
Page 45 Chapter 4: Motherboard Connections Onboard Battery (BT1) The onboard back up battery is located at BT1. The onboard battery provides backup power to the on-chip CMOS, which stores the BIOS setup information. It also provides power to the Real Time Clock (RTC) to keep it running. Chassis Intrusion (JL1) A Chassis Intrusion header is located at JL1 on the motherboard.
Page 46 JFP1 contains header pins for various buttons and indicators that are normally located on a control panel at the front of the chassis. These connectors are designed specifically for use with Supermicro chassis. See the figure below for the location of JFP1. MH14...
Page 47 Chapter 4: Motherboard Connections Front Control Panel Pin Definitions Power LED The Power LED connection is located on pins 8 and 9 of JFP1. Refer to the table below for pin definitions. Power LED Pin Definitions (JF1) Pin# Definition Standby Power LED- Normal Power LED- Drive Activity LED The Drive Activity LED connection is located on pin 7 of JFP1.
Page 48 Chapter 4: Motherboard Connections UID LED The UID LED is on pin 3 of JFP1. Connect the front panel UID LED to this header to indicate when the rear UID switch is turned on. Refer to the table below for pin definitions. UID LED Pin Definitions (JFP1) Pin#...
Page 49 Chapter 4: Motherboard Connections 4.3 LED Indicators UID LED (UID_LED1) The UID LED is located next to two buttons at one of the corners of the motherboard. One of the buttons is the UIDBTN1 button. Press this button and the LED will blink blue to show that the UID is active.
Page 50 Chapter 4: Motherboard Connections M.2 Activity LEDs ACT_LED1 and ACT_LED2 are onboard M.2 LEDs. When these LEDs are blinking green, the M.2 SSD is active. M.2 Activity LEDs State Definition M.2 Inactive Blinking green M.2 Active EROT Detected LEDs (LED1 and LED2) The EROT Detected OK LED (LED1) and the EROT Detected Fail LED (LED2) shows the status of the Root-of-Trust (RoT).
Page 51 Chapter 4: Motherboard Connections 4.4 M.2 Solid State Drive Installation Installing Dual M.2 SSDs 1. Disconnect power from the motherboard or system. 2. Refer to the motherboard layout and locate the M.2 dual slots (JM2A/JM2B). 3. Insert the lower M.2 sideways into the connector so that it lays flat, then follow the instructions below from 4.
Page 52 Chapter 5: Software Chapter 5 Software After the hardware has been installed, you can boot the Operating System (OS). Additionlly, the following software is supported on the G1SMH. 5.1 Ubuntu Server 22.04 ISO Installation ® Prerequisites Obtain the Ubuntu Server ISO for ARM image (aarch64) and save it to your local disk or a shared server.
Page 53 DisplayPort-to-DisplayPort (DP) adapter. Ensure that network is connected to BMC using a network cable and power on the system. The BMC IP address will appear on the right corner of the Supermicro Logo screen. Step 2. Accessing the BMC Remote Server Log in to the BMC Remote Server 1.
Page 54 Chapter 5: Software 3. Input the username "ADMIN" and the unique BMC password, which is located on the label on the opposite side of the service tag of the system. Click "Login" to proceed. Outcome: The BMC Dashboard offers insights into system overview, configuration, health status, and maintenance.
Page 55 Chapter 5: Software Step 3. Controlling the BMC Remotely 1. The Remote Control menu in the BMC Remote Server enables remote server operations. 2. Use the Launch Console section to configure the remote console interface settings. Choose between the HTML5 interface or a JAVA plug-in.
Page 56 Chapter 5: Software Launch an HTML5 Remote Browser 1. Set HTML5 as the current interface. 2. Choose the mouse mode according to your operating system, such as "Set Mode to Absolute (Windows, Ubuntu, RH6.x, or later)". 3. Click the "Launch Console" button to open a console in a new browser window.
Page 57 Chapter 5: Software Step 4. Mounting the ISO Image There are two methods to mount ISO images. If the ISO files are stored locally on your disk, you can mount them directly within the remote control browser. Alternatively, if the ISO files are located on a shared server, you can mount them via the Configuration >...
Page 58 Chapter 5: Software 2. Click the "Select File" button to browse and choose the Ubuntu ISO image on your local disk for use.
Page 59 Chapter 5: Software 3. Click the "Mount" button to attach the chosen ISO image. Result: Upon successful mounting of the ISO image, a green indicator will appear in the "Device" tab. Close the dialogue to continue.
Page 60 Chapter 5: Software Method Two: Mount the ISO Image through a Shared Server 1. On the BMC dashboard, go to Configuration > Virtual Media, this allows you to attach an ISO image from the server. 2. Click the "Edit" icon to adjust the VM configuration. Enter the server host address and the path to the ISO image.
Page 61 Chapter 5: Software 3. Click the "Connect" icon to mount the virtual media. The device status will display as green once the VM is successfully configured. The device status will display as green once the VM is successfully configured.
Page 62 Chapter 5: Software Step 5. Setting Boot Override in UEFI BIOS To configure the boot option from the mounted image in virtual media, users must manually adjust the boot settings in the BIOS setup. 1. Power on the system and wait for the Log screen to display. To access the BIOS setup menu, repeatedly press <DEL>...
Page 63 Chapter 5: Software Subsequently, the UEFI BIOS screen is displayed. 2. Navigate to the "Save & Exit" menu using the arrow keys, then select "UEFI: ATEN Virtual CDROM YSOJ" as the boot option. This selection presents the ISO image mounted in Virtual Media. Hit "Enter" to proceed.
Page 64 Chapter 5: Software 3. Follow the Ubuntu installer steps to continue installation. Choose "Ubuntu Server with the HWE kernel" to proceed. Step 6. Installing Ubuntu 22.04 OS 1. In the Ubuntu installer, select the language.
Page 65 Chapter 5: Software 2. Configure the keyboard options. 3. Select "Ubuntu Server" as the base for the installation. 4. Configure the network connection to proceed. If an Ethernet network connection is available, proceed by selecting at least one network configuration option displayed on the installation UI.
Page 66 Chapter 5: Software 5. Configure the Ubuntu archive mirror address and run the test. Proceed with the following message: "This mirror location passed tests." If Ethernet is disconnected during the installation process, please proceed with the following message: "The mirror location cannot be checked because no network has been configured."...
Page 67 Chapter 5: Software 7. Set one of the disks as the boot device. You may choose either a disk or an USB drive as your boot device. 8. Create GPT partitions from the free space in the disk. To continue installation, at least two partitions are required to proceed: one mount point at "/boot/efi"...
Page 68 Chapter 5: Software 9. Select the size, format, and mount point when adding GPT partition to the boot disk.
Page 69 Chapter 5: Software 10. Create the profile name, server name, username, and password. 11. Wait until the installation is complete and reboot the system.
Page 70 Chapter 5: Software 12. Enter username and password to log in. Log in successfully.
Page 71 DisplayPort-to-DisplayPort (DP) adapter. Ensure that the network is connected to the BMC using a network cable and power on the system. The BMC IP address will appear on the right corner of the Supermicro Logo screen. Step 2. Accessing the BMC Remote Server Log in to the BMC Remote Server 1.
Page 72 Chapter 5: Software 2. Launch a new web browser and input the BMC IP address into the URL field. Outcome: The BMC Remote Console login screen will be displayed. 3. Input the username "ADMIN" and the unique BMC password, which is located on the label on the opposite side of the service tag of the system.
Page 73 Chapter 5: Software Outcome: The BMC Dashboard offers insights into system overview, configuration, health status, and maintenance. Step 3. Controlling the BMC Remotely 1. The Remote Control menu in the BMC Remote Server enables remote server operations.
Page 74 Chapter 5: Software 2. Use the Launch Console section to configure the remote console interface settings. Choose between the HTML5 interface or a JAVA plug-in. Launch an HTML5 Remote Browser 1. Set HTML5 as the current interface. 2. Choose the mouse mode according to your operating system, such as "Set Mode to Absolute (Windows, Ubuntu, RH6.x, or later)."...
Page 75 Chapter 5: Software Step 4. Mounting the ISO image There are two methods to mount ISO images. If the ISO files are stored locally on your disk, you can mount them directly within the remote control browser. Alternatively, if the ISO files are located on a shared server, you can mount them via the Configuration >...
Page 76 Chapter 5: Software 2. Click the "Select File" button to browse and choose the RHEL ISO image from your local disk for use.
Page 77 Chapter 5: Software 3. Click the "Mount" button to attach the selected ISO image. Result: Upon successful mounting of the ISO image, a green indicator will appear in the "Device" tab. Close the dialogue to continue.
Page 78 Chapter 5: Software Method Two: Mount the ISO Image through a Shared Server 1. On the BMC dashboard, go to Configuration > Virtual Media. This allows you to attach an ISO image from the server. 2. Click the "Edit" icon to adjust the VM configuration. Enter the server host address and the path to the ISO image.
Page 79 Chapter 5: Software 3. Click the "Connect" icon to mount the virtual media. 4. The device status will display as green once the VM is successfully configured. Step 5. Setting Boot Override in UEFI BIOS To configure the boot option from the mounted image in virtual media, users must manually adjust the boot settings in the BIOS setup.
Page 80 Chapter 5: Software Subsequently, the UEFI BIOS screen is displayed. 2. Navigate to the "Save & Exit" menu using the arrow keys, then select "UEFI: ATEN Virtual CDROM YSOJ" as the boot option. This selection presents the ISO image mounted in Virtual Media. Hit "Enter" to proceed.
Page 81 Chapter 5: Software 3. Follow the RHEL installer steps to continue installation. Choose "Install Red Hat Enterprise Linux 9.3" to proceed. Step 6. Installing RHEL 9.3 OS 1. In the RHEL installer, select the language.
Page 82 Chapter 5: Software 2. The Installation Summary window provides a glance of the configuration you need before you begin the installation. 3. Click the "Installation Destination" button to select the storage dirve.
Page 83 Chapter 5: Software 4. Select the disk to which you want to install the RHEL OS. 5. Select one of the disks and select "Custom" if you want to customize the volume of the disk.
Page 84 Chapter 5: Software It will show you the space of the disk you selected. 6. For RHEL, you need to have at least three mount points (/boot/efi, /, and swap). Click the "+" button to create new mount point "/boot/efi" as the boot partition for EFI system.
Page 85 Chapter 5: Software 7. The "Add a new mount point" dialogue will pop up. Select the mount point "/boot/efi" and the storage size. Then, click the "Add mount point" button. Result: The new mount point "/boot/efi" will be added under the "New Red Hat Enterprise Linux 9.3 Installation".
Page 86 Chapter 5: Software 8. Click the "+" button to create another new mount point "/" as the root directory. Configure the mount point "/" and the desired storage size. Then, click the "Add mount point" button. Result: The new mount point "/" will be added under the "New Red Hat Enterprise Linux 9.3 Installation".
Page 87 Chapter 5: Software 9. Click the "+" button to create another new mount point "swap" for virtual memory space. Configure the mount point "swap" and the desired storage size. Then, click the "Add mount point" button. Result: The new mount point "swap" will be added under the "New Red Hat Enterprise Linux 9.3 Installation."...
Page 88 Chapter 5: Software 10. Click the "Done" button at the left top corner after all the required partitions are created. 11. Accept the changes for customize partitions.
Page 89 Chapter 5: Software Result: In the "Installation Summary" screen, Installation Destination has been updated to "Custom partitioning selected." 12. Click the "Root Password" in the "Installation Summary".
Page 90 Chapter 5: Software 13. Enter the password for the root user. Result: The status of the Root User becomes "Root password is set".
Page 91 Chapter 5: Software 14. Click "User Creation" in "Installation Summary". 15. Enter "Full Name", "User Name" , "Password" and "Confirm Password" details. Once done, click the "Done" button. Result: The status of User Creation becomes "User username is set".
Page 92 Chapter 5: Software 16. After completing all the above steps, click "Begin Installation" to start the installation process.
Page 93 Chapter 5: Software 17. After the installation is complete, click "Reboot System" to reboot.
Page 94 Chapter 5: Software 18. After rebooting, the user login page will appear. Enter the user password to log in. Result: Log in successfully. You can start using this system.
Page 95 Chapter 5: Software 5.3 SUSE Linux Enterprise Server 15 Installation Prerequisites Obtain the SUSE Linux Enterprise Server 15 ISO for ARM image (aarch64) and save it to your local disk or a shared server. It’s recommended to use the SLES 15SP5 ISO image file. Please refer to Downloading a SLES 15 installation ISO image for the ISO packages.
Page 96 DisplayPort-to-DisplayPort (DP) adapter. Ensure that network is connected to the BMC using a network cable and power on the system. The BMC IP address will appear on the right corner of the Supermicro Logo screen. Step 2. Accessing the BMC Remote Server Log in to BMC Remote Server 1.
Page 97 Chapter 5: Software 3. Input the username "ADMIN" and the unique BMC password, which is located on the label on the opposite side of the service tag of the system. Click "Login" to proceed. Outcome: The BMC Dashboard offers insights into system overview, configuration, health status, and maintenance.
Page 98 Chapter 5: Software Step 3. Controlling the BMC Remotly 1. The Remote Control menu in the BMC Remote Server enables remote server operations. 2. Use the Launch Console section to configure the remote console interface settings. Choose between the HTML5 interface or a JAVA plug-in. Launch an HTML5 remote browser.
Page 99 Chapter 5: Software To launch an HTML5 Remote Browser 1. Set HTML5 as the current interface. 2. Choose the mouse mode according to your operating system, such as "Set Mode to Absolute" (Windows, Ubuntu, RH6.x, or later)." 3. Click the "Launch Console" button to open a console in a new browser window.
Page 100 Chapter 5: Software Step 4. Mounting the ISO Image There are two methods to mount ISO images. If the ISO files are stored locally on your disk, you can mount them directly within the remote control browser. Alternatively, if the ISO files are located on a shared server, you can mount them via the Configuration >...
Page 101 Chapter 5: Software 2. Click the "Select File" button to browse and choose the SLES ISO image on your local disk for use.
Page 102 Chapter 5: Software 3. Click the "Mount" button to attach the chosen ISO image. Result: Upon successful mounting of the ISO image, a green indicator will appear in the "Device" tab. Close the dialogue to continue.
Page 103 Chapter 5: Software Method Two: Mount the ISO Image through Shared Server 1. On the BMC dashboard, go to Configuration > Virtual Media. This allows you to attach an ISO image from the server. 2. Click the "Edit" icon to adjust the VM configuration. Enter the server host address and the path to the ISO image.
Page 104 Chapter 5: Software 3. Click the "Connect" icon to mount the virtual media. 4. The device status will display as green once the VM is successfully configured. Step 5. Entering in UEFI BIOS Menu To configure the boot option from the mounted image in virtual media, users must manually adjust the boot settings in the BIOS setup.
Page 105 Chapter 5: Software Subsequently, the UEFI BIOS screen is displayed. Step 6. Opening a SSH SOL Connection in PuTTY Open a connection to the BMC IP address (For detailed instructions, refer to Step 1. Obtaining BMC IP Address.) and log in using the provided username and the unique BMC password through PuTTY.
Page 106 Chapter 5: Software Step 7. Setting the Boot Option in PuTTY Terminal 1. Navigate to the "Save & Exit" menu using the arrow keys in PuTTY terminal, then select "UEFI: ATEN Virtual CDROM YSOJ" as the boot option. This selection presents the ISO image mounted in Virtual Media.
Page 107 Chapter 5: Software 2. Select "Installation" and press "t" to show the boot menu in PuTTY terminal.
Page 108 Chapter 5: Software 3. Highlight "Installation" and press "e" to edit the commands. 4. Append "modprobe.blacklist=ast" to the end of the list of kernel boot parameters. Boot the entry by clicking the Ctrl-X or pressing F10.
Page 109 Chapter 5: Software Step 8. Installing SLES 15 OS Follow the SLES Installer Steps in PuTTY to Continue Installation 1. Initialize network configuration. 2. Select the Language, Keyboard, and Product to install.
Page 110 Chapter 5: Software 3. Review the End User Agreement and proceed if you agree to the License Terms. 4. Configure the Network settings.
Page 111 Chapter 5: Software 5. Fill in the Registration details. 6. Select Add-on Products if you want to install.
Page 112 Chapter 5: Software 7. Define the System Role based on your specific use case. This role will dictate the installation selections tailored to your requirements. 8. Choose the partitioning scheme that best suits your requirements.
Page 113 Chapter 5: Software 9. Select the Clock and Time Zone. 10. Set up local username and password.
Page 114 Chapter 5: Software 11. Set up System administrator "root" and its password. 12. Review the Installation Settings and click "Install" to start the installation process.
Page 115 Chapter 5: Software...
Page 116 Chapter 5: Software 13. Once installation is complete, the system will reboot. 14. Select "SLES 15-SP5" and click "Enter" to proceed in the remote control.
Page 117 Chapter 5: Software 15. Enter username and password to login. Log in successfully.
Page 118 Chapter 5: Software 5.4 SuperDoctor® 5 The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).
Page 119 Chapter 6: Optional Components Chapter 6 Optional Components This chapter describes optional system components and installation procedures. 6.1 Storage Drives The default configuration includes total four front hot-swap E1.S NVMe drives and AOC networking card (Follow list).
Page 120 Chapter 7: Troubleshooting and Support Chapter 7 Troubleshooting and Support 7.1 Information Resources Website A great deal of information is available on the Supermicro website. Figure 7-1. Supermicro Website • Specifications for servers and other hardware are available by clicking Products option. •...
Page 121 Security Center for recent security notices. Supermicro Phone and Addresses 7.2 Baseboard Management Controller (BMC) This system supports the Baseboard Management Controller (BMC). BMC is used to provide remote access, monitoring, and management. There are several BIOS settings that are related to BMC.
Page 122 In the event of a processor internal error (IERR) that crashes your system, you may want to provide information to support staff. You can download a crash dump of status information using the BMC Dashboard. The BMC manual is available at https://www.supermicro.com/manuals/other/BMC_IPMI_X13_H13.pdf. Check Error Log 1. Access the BMC web interface.
Page 123 Chapter 7: Troubleshooting and Support 7.4 CMOS Clear JBT1 is used to clear CMOS, which will also clear any passwords. Instead of pins, this jumper consists of contact pads to prevent accidentally clearing the contents of CMOS. To Clear CMOS 1.
Page 124 Before contacting Technical Support, please take the following steps. Also, please note that as a motherboard manufacturer, Supermicro also sells motherboards through its channels, so it is best to first check with your distributor or reseller for troubleshooting services. They should know of any possible problems with the specific system configuration that was sold to you.
Page 125 For issues related to Red Hat Enterprise Linux, since it is a subscription based OS, contact your account representative. 7.8 Feedback Supermicro values your feedback as we strive to improve our customer experience in all facets of our business. Please email us at techwriterteam@supermicro.com to provide feedback on our manuals.
Page 126 San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) Sales-USA@supermicro.com (Sales Inquiries) Government_Sales-USA@supermicro.com (Gov. Sales Inquiries) support@supermicro.com (Technical Support) RMA@supermicro.com (RMA Support) Webmaster@supermicro.com (Webmaster) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.
Page 127 Chapter 8: BIOS Chapter 8 BIOS This chapter describes optional system components and installation procedures. 8.1 Introduction This chapter describes the AMIBIOS™ Setup utility for the G1SMH motherboard. The BIOS is stored on a chip and can be easily upgraded using a flash program. Note: Due to periodic changes to the BIOS, some settings may have been added or deleted and might not yet be recorded in this manual.
Page 128 Chapter 8: BIOS 8.2 Main Setup When you first enter the AMI BIOS setup utility, you will enter the Main setup screen. You can always return to the Main setup screen by selecting the Main tab on the top of the screen. The Main BIOS setup screen is shown below.
Page 129 Chapter 8: BIOS Build Date This item displays the date when the version of the BIOS ROM used in the system was built. FPGA Version This item displays the FPGA version used in the system. Memory Information Total Memory This item displays the total size of memory available in the system.
Page 130 Chapter 8: BIOS 8.3 Advanced Use the arrow keys to select Advanced Setup and press <Enter> to access the submenu items. Boot Feature Quiet Boot Use this feature to select the screen display between the Power-on Self Test (POST) messages and the OEM logo upon bootup. Select Disabled to display the POST messages. Select Enabled to display the OEM logo instead of the normal POST messages.
Page 131 Chapter 8: BIOS Watch Dog Function If enabled, the Watch Dog Timer will allow the system to reset or generate NMI based on jumper settings when it is expired for more than 5 minutes. The options are Disabled and Enabled. Serial Port Console Redirection COM0 Console Redirection...
Page 132 Chapter 8: BIOS VT-UTF8 Combo Key Support The options include Disabled and Enabled. Recorder Mode Select Enabled to capture the data displayed on a terminal and send it as text messages to a remote server. The options are Disabled and Enabled. Resolution 100x31 Select Enabled for extended-terminal resolution support.
Page 133 Chapter 8: BIOS Flow Control EMS Use this feature to set the flow control for Console Redirection to prevent data loss caused by buffer overflow. Send a "Stop" signal to stop sending data when the receiving buffer is full. Send a "Start" signal to start sending data when the receiving buffer is empty. The options are None, Hardware RTS/CTS, Software Xon/Xoff.
Page 134 Chapter 8: BIOS South Bridge USB Module Version USB Devices: Legacy USB Support This feature enabled legacy USB support. The options are Enabled, Disabled, and Auto. Trusted Computing Configuration Security Device Support If this feature and the TPM jumper on the motherboard are both set to Enabled, onboard security devices will be enabled for TPM (Trusted Platform Module) support to enhance data integrity and network security.
Page 135 Chapter 8: BIOS Bits Per Second Use this feature to set the transmission speed for a serial port used in Console Redirection. Make sure that the same speed is used in the host computer and the client computer. A lower transmission speed may be required for long and busy lines. The options are 9600, 19200, 384000, 57600, 115200, 230400, 460800, and 921600 (bits per second).
Page 136 Chapter 8: BIOS Console Redirection Settings Out-of-Band Mgmt Port Terminal Type This feature allows the user to select the target terminal emulation type for Console Redirection. Select VT100 to use the ASCII Character set. Select VT100+ to add color and function key support. Select ANSI to use the Extended ASCII Character Set. Select VT-UTF8 to use UTF8 encoding to map Unicode characters into one or more bytes.
Page 137 Chapter 8: BIOS PCI-X Latency Timer Use this feature to set the PCI latency timer register. The options are 32 PCI Bus Clocks, 64 PCI Bus Clocks, 96 PCI Bus Clocks, 128 PCI Bus Clocks, 160 PCI Bus Clocks, 192 PCI Bus Clocks, 224 PCI Bus Clocks, and 248 PCI Bus Clocks.
Page 138 Chapter 8: BIOS No Snoop This feature enables or disables the no snoop option on a PCIe device. The options are Disabled and Enabled. Maximum Payload This feature sets the maximum payload of the PCIe device. The options are Auto, 128 Bytes, 256 Bytes, 512 Bytes, 1024 Bytes, 2048 Bytes, and 4096 Bytes.
Page 139 Chapter 8: BIOS PCI Express GEN 2 Settings PCI Express GEN2 Device Register Settings Completion Timeout This feature allows system software to modify the Completion Timeout value. The options are Default, Shorter, Longer and Disabled. ARI Forwarding This feature disables the traditional device number field and permits access to extended functions in an ARI device.
Page 140 Chapter 8: BIOS PCI Express GEN2 Link Register Settings Target Link Speed This feature sets an upper limit on Link operational speed by restricting the values adver- stised by the Upstream component in its training sequence. If set to Auto, the hardware initialized data will be used.
Page 141 Chapter 8: BIOS USB Mass Storage Driver Support This feature enables the USB mass storage driver support. The options are Disabled and Enabled. USB hardware delays and time-outs: USB transfer time-out This feature sets the time-out value for control, bulk, and interrupt transfers. The options are 1 sec, 5 sec, 10 sec, and 20 sec.
Page 142 Chapter 8: BIOS CPU Configuration CPU Configuration Number of processors Processor type Number of cores Number of Active cores Processor clock L1 Instruction cache L1 Data cache L2 cache Processor type Number of cores Number of cores Enabled Processor Speed L1 Instruction cache L1 Data cache L2 cache...
Page 143 Chapter 8: BIOS RT PPS ENABLED ONPOWERUP This item enables or disables the FT PPS on power up. The default is Disabled. Device Level Configuration Virtualization Mode This item specifies the type of virtualization used by the controller on all ports. The options are None and SR-IOV.
Page 144 Chapter 8: BIOS Device Name This feature displays the official product name of the device. Chip Type This feature displays the chip type. PCI Device ID This feature displays the PCI Device ID of the controller. PCI Address This feature displays the PCI Device ID of the controller. Link Status This feature displays the Link Status of the controller.
Page 145 Chapter 8: BIOS Firmware Image Properties Family Firmware This item displays the firmware version of the Nvidia Network Adapter used in the system. EFI Version This item displays the EFI version of the Nvidia Network Adapter used in the system. Power Configuration RT PPS ENABLED ONPOWERUP This item enables or disables the FT PPS on power up.
Page 146 Chapter 8: BIOS This feature defines the whether the internal CPU is used as an offload engine. The options are ECPF and EXT HOST PF. VMware Distributed Services Engine (DPU) This feature enables or disables the VMware Distributed Services Enginer (DPU). The options are Disabled and Enabled.
Page 147 Chapter 8: BIOS Save Changes and Exit This feature save the changes and exits. Tls Auth Configuration This submenu allows the user to configure Transport Layer Security (TLS) settings. Server CA Configuration Enroll Certification Enroll Certification Using File Use this feature to enroll certification from a file. Certification GUID Use this feature to enroll to input the certification GUID.
Page 148 Chapter 8: BIOS Use this option to create a raw RAM disk. Delete from file Use this option to create a RAM disk from a given file. Created RAM disk list: Remove selected RAM disk(s) Use this option to remove the selected RAM disks. NVIDIA Configuration Serial Port Configuration Use this option to select serial port configuration.
Page 149 Chapter 8: BIOS Use this option to allow GPU SMMI bypass when the kernel SMMU driver is configured to work in passthrough mode. The options are Disabled and Enabled. Socket 0 configuration UPHY 0 config Use this option to configure PCIe C0+C1. The options are Disabled, PCIe C0 - x16, and PCIe C0 x8 - C1 x8.
Page 150 Chapter 8: BIOS Enable ECRC This feature enables the ECRC in the controllers hierarchy. The options are Disabled and Enabled. Disable DPC at RP This feature disables DPC at RP if a DPC capable PCIe switch is connected to RP. The options are Disabled and Enabled.
Page 151 Chapter 8: BIOS This feature configures DL feature exchange. The options are Disabled and Enabled. Enable ECRC This feature enables the ECRC in the controllers hierarchy. The options are Disabled and Enabled. Disable DPC at RP This feature disables DPC at RP if a DPC capable PCIe switch is connected to RP. The options are Disabled and Enabled.
Page 152 Chapter 8: BIOS Set the availability of the ClkReq signal from RP to EP. The options are Disabled and Enabled. Disable DLFE This feature configures DL feature exchange. The options are Disabled and Enabled. Enable ECRC This feature enables the ECRC in the controllers hierarchy. The options are Disabled and Enabled.
Page 153 Chapter 8: BIOS Set the availability of the ClkReq signal from RP to EP. The options are Disabled and Enabled. Disable DLFE This feature configures DL feature exchange. The options are Disabled and Enabled. Enable ECRC This feature enables the ECRC in the controllers hierarchy. The options are Disabled and Enabled.
Page 154 Chapter 8: BIOS PCI-PM L1.2 support This feature configures PCI-PM L1.2. The options are Disabled and Enabled. Supports ClkReq Set the availability of the ClkReq signal from RP to EP. The options are Disabled and Enabled. Disable DLFE This feature configures DL feature exchange. The options are Disabled and Enabled. Enable ECRC This feature enables the ECRC in the controllers hierarchy.
Page 155 Chapter 8: BIOS PCI-PM L1.2 support This feature configures PCI-PM L1.2. The options are Disabled and Enabled. Supports ClkReq Set the availability of the ClkReq signal from RP to EP. The options are Disabled and Enabled. Disable DLFE This feature configures DL feature exchange. The options are Disabled and Enabled. Enable ECRC This feature enables the ECRC in the controllers hierarchy.
Page 156 Chapter 8: BIOS Enable ASPM L1.2 This feature configures ASPM L1.2. The options are Disabled and Enabled. PCI-PM L1.2 support This feature configures PCI-PM L1.2. The options are Disabled and Enabled. Supports ClkReq Set the availability of the ClkReq signal from RP to EP. The options are Disabled and Enabled.
Page 157 Chapter 8: BIOS Enable ASPM L1.2 This feature configures ASPM L1.2. The options are Disabled and Enabled. PCI-PM L1.2 support This feature configures PCI-PM L1.2. The options are Disabled and Enabled. Supports ClkReq Set the availability of the ClkReq signal from RP to EP. The options are Disabled and Enabled.
Page 158 Chapter 8: BIOS This feature configures ASPM L1. The options are Disabled and Enabled. Enable ASPM L1.1 This feature configures ASPM L1.1. The options are Disabled and Enabled. Enable ASPM L1.2 This feature configures ASPM L1.2. The options are Disabled and Enabled. PCI-PM L1.2 support This feature configures PCI-PM L1.2.
Page 159 Chapter 8: BIOS Max PCIe width Set the max PCIe width. The options are x16, x8, x4, x2, and x1. Enable ASPM L1 This feature configures ASPM L1. The options are Disabled and Enabled. Enable ASPM L1.1 This feature configures ASPM L1.1. The options are Disabled and Enabled. Enable ASPM L1.2 This feature configures ASPM L1.2.
Page 160 Chapter 8: BIOS PCIe C0 Configuration Max PCIe speed Set the maximum PCIe speed. The options are Gen5, Gen4, Gen3, Gen2, and Gen1. Max PCIe width Set the max PCIe width. The options are x16, x8, x4, x2, and x1. Enable ASPM L1 This feature configures ASPM L1.
Page 161 Chapter 8: BIOS PCIe C1 Configuration Max PCIe speed Set the maximum PCIe speed. The options are Gen5, Gen4, Gen3, Gen2, and Gen1. Max PCIe width Set the max PCIe width. The options are x16, x8, x4, x2, and x1. Enable ASPM L1 This feature configures ASPM L1.
Page 162 Chapter 8: BIOS UPHY 1 config Use this option to configure PCIe C2+C3. The options are Disabled, PCIe C2 - x16, and PCIe C2 x8 - C3 x8. PCIe C2 Configuration Max PCIe speed Set the maximum PCIe speed. The options are Gen5, Gen4, Gen3, Gen2, and Gen1. Max PCIe width Set the max PCIe width.
Page 163 Chapter 8: BIOS Disable DPC at RP This feature disables DPC at RP if a DPC capable PCIe switch is connected to RP. The options are Disabled and Enabled. PCIe C3 Configuration Max PCIe speed Set the maximum PCIe speed. The options are Gen5, Gen4, Gen3, Gen2, and Gen1. Max PCIe width Set the max PCIe width.
Page 164 Chapter 8: BIOS Disable DPC at RP This feature disables DPC at RP if a DPC capable PCIe switch is connected to RP. The options are Disabled and Enabled. UPHY 2 config Use this option to configure PCIe C4+C5+NVLINK. The options are Disabled, PCIe C4 - x16, and PCIe C4 x8 - C5 x8, PCIe C4 x8 - C5 x8, and PCIe C5 x4 - NVLINK x12.
Page 165 Chapter 8: BIOS Enable ECRC This feature enables the ECRC in the controllers hierarchy. The options are Disabled and Enabled. Disable DPC at RP This feature disables DPC at RP if a DPC capable PCIe switch is connected to RP. The options are Disabled and Enabled.
Page 166 Chapter 8: BIOS This feature configures DL feature exchange. The options are Disabled and Enabled. Enable ECRC This feature enables the ECRC in the controllers hierarchy. The options are Disabled and Enabled. Disable DPC at RP This feature disables DPC at RP if a DPC capable PCIe switch is connected to RP. The options are Disabled and Enabled.
Page 167 Chapter 8: BIOS Supports ClkReq Set the availability of the ClkReq signal from RP to EP. The options are Disabled and Enabled. Disable DLFE This feature configures DL feature exchange. The options are Disabled and Enabled. Enable ECRC This feature enables the ECRC in the controllers hierarchy. The options are Disabled and Enabled.
Page 168 Chapter 8: BIOS Supports ClkReq Set the availability of the ClkReq signal from RP to EP. The options are Disabled and Enabled. Disable DLFE This feature configures DL feature exchange. The options are Disabled and Enabled. Enable ECRC This feature enables the ECRC in the controllers hierarchy. The options are Disabled and Enabled.
Page 169 Chapter 8: BIOS PCI-PM L1.2 support This feature configures PCI-PM L1.2. The options are Disabled and Enabled. Supports ClkReq Set the availability of the ClkReq signal from RP to EP. The options are Disabled and Enabled. Disable DLFE This feature configures DL feature exchange. The options are Disabled and Enabled. Enable ECRC This feature enables the ECRC in the controllers hierarchy.
Page 170 Chapter 8: BIOS Enable ASPM L1.2 This feature configures ASPM L1.2. The options are Disabled and Enabled. PCI-PM L1.2 support This feature configures PCI-PM L1.2. The options are Disabled and Enabled. Supports ClkReq Set the availability of the ClkReq signal from RP to EP. The options are Disabled and Enabled.
Page 171 Chapter 8: BIOS Priority This feature displays the 802.1Q Priority of the new VLAN. The range of the value is from 0 to 7. Add VLAN Configured VLAN list Use this feature remove the VLAN from the configured VLAN list. The options are Disabled and Enabled.
Page 172 Chapter 8: BIOS Priority This feature displays the 802.1Q Priority of the new VLAN. The range of the value is from 0 to 7. Add VLAN Configured VLAN list Use this feature remove the VLAN from the configured VLAN list. The options are Disabled and Enabled.
Page 173 Chapter 8: BIOS Driver At Handle 659D4D18 Mellanox ConnectX Driver Controller 641F7F18 Child 0 Healthy Controller 641F7F18 Child 63A20E98 Healthy Mellanox ConnectX Driver Controller 641F7298 Child 0 Healthy Controller 641F7298 Child 6388AF98 Healthy...
Page 174 Chapter 8: BIOS 8.4 BMC This tab allows you to configure the following Chipset settings for the system. BMC Firmware Revision BMC STATUS FRB-2 Timer This feature enables or disables FRB-2 timer. The options are Enabled and Disabled. FRB-2 Timer timeout This setting configures the FRB-2 Timer expiration.
Page 175 Chapter 8: BIOS OS Wtd Timer Timeout OS Wtd Timer Policy Serial Mux This setting enables or disables Serial Mux configuration. The options are Enabled and Disabled. System Event Log Enabling/Disabling Options SEL Components Set this feature to enable or disable event logging for error codes during boot. The options are Disabled and Enabled.
Page 176 Chapter 8: BIOS Board Part Number Board Serial Number Chassis Manufacturer Chassis Part Number Chassis Serial Number SDR Version System UUID Bmc self test log Log area usage = 00 out of 20 logs Erase Log This feature selects when to erase logs. The options are Yes, On every reset and No. When log is full This feature selects what to do when the log is full.
Page 177 Chapter 8: BIOS Lan channel 2 Configuration Address source This feature configures the LAN parameter statically or dynamically. The options are Unspecified, Static, DynamicBmcDhcp, and DynamicBmcNonDhcp. Current Configuration Address source Station IP address Subnet mask Station MAC address Router MAC address ***************************** Configure IPv6 support *****************************...
Page 178 Chapter 8: BIOS Lan channel 2 IPv6 Support This feature enables or disables LAN1 IPv6 Support. The options are Enabled and Disabled. Configuration Address source This feature configures the LAN parameter statically or dynamically. The options are Unspecified, Static, DynamicBmcDhcp, and DynamicBmcNonDhcp. Current Configuration Address source Station IPv6 address Prefix Length...
Page 179 Chapter 8: BIOS This feature enables VLAN support to specify the 802.1q VLAN ID. The options are Enabled, Disabled, and Unspecified. Current Configuration Address source VLAN ID VLAN Priority View System Event Log This feature allows the user to retrieve all system event logs. BMC User Settings BMC User Settings Add User...
Page 180 Chapter 8: BIOS 8.5 Security This tab allows you to configure the following Security settings for the system. Password Description The section describes the Administrator's password and the User's password. Administrator Password This feature allows the user to set the Administrator Password. User Password This feature allows the user to set the User Password.
Page 181 Chapter 8: BIOS Secure Boot Mode Use this item to select the secure boot mode. The options are Standard and Custom. Restore Factory Keys Reset to Setup Mode Expert Key Management TCG Storage Security Configuration:...
Page 182 Chapter 8: BIOS 8.6 Boot This tab allows the user to configure the following boot settings for the system. Boot Option Priorities Boot Option #1 This option sets the system boot order. The options are UEFI: Built-in EFI Shell, UEFI: PXE IPv4 Nvidia Network Adapter - 94:6D:AE:C7:77:14, UEFI: PXE IPv4 Nvidia Network Adapter - 94:6D:AE:C7:77:15, and Disabled.
Page 183 Chapter 8: BIOS Fast Boot This option sets the minimum number of devices required to launch the active boot option. The choices are Disable Link and Enabled. Driver Option Priorities Add New Boot Option Add New Boot Option Add boot option This option sets the boot option.
Page 184 Chapter 8: BIOS 8.7 Save & Exit Select the Save & Exit tab to enter the Save & Exit BIOS Setup screen. Save Options Discard Changes and Exit Select this option to quit the BIOS Setup without making any permanent changes to the system configuration, and reboot the computer.
Page 185 Chapter 8: BIOS Default Options Restore Defaults To set this feature, select Restore Defaults from the Save & Exit menu and press <Enter>. These are factory settings designed for maximum system stability, but not for maximum performance. Save as User Defaults To set this feature, select Save as User Defaults from the Exit menu and press <Enter>.
Page 186 Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
Page 187 Appendix A: Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
Page 188 Appendix A: Warning Statements . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬ ٍ...
Page 189 Appendix A: Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
Page 190 Appendix A: Warning Statements Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
Page 191 Appendix A: Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components (except for hot-swap components). 電源切断の警告...
Page 192 Appendix A: Warning Statements ‫אזהרה מפני ניתוק חשמלי‬ ‫!אזהרה‬ ‫יש לנתק את המערכת מכל מקורות החשמל ויש להסיר את כבל החשמלי מהספק‬ ‫.לפני גישה לחלק הפנימי של המארז לצורך התקנת או הסרת רכיבים‬ ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬ ‫انطاقت...
Page 193 Appendix A: Warning Statements Attention Seul le personnel autorisé et le personnel de maintenance qualifié doivent être autorisés à installer, remplacer ou entretenir cet équipement.. !‫אזהרה‬ ‫.יש לאפשר רק צוות מורשה ואנשי שירות מוסמכים להתקין, להחליף או לטפל בציוד זה‬ ‫.ينبغي...
Page 194 Appendix A: Warning Statements Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial, cerradura con llave u otro medio de seguridad.
Page 195 Appendix A: Warning Statements Battery Handling CAUTION: There is risk of explosion if the battery is replaced by an incorrect type. Replace the battery only with the same or equivalent type recommended by the manu- facturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
Page 196 Appendix A: Warning Statements ‫.هناك خطر االنفجار إذا تم استبدال البطارية بنوع غري صحيح‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리를 잘못된 종류로 교체하면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제조 사에서...
Page 197 Appendix A: Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
Page 198 Appendix A: Warning Statements Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧システムの稼働中は危険な電圧または電力が、バックプレーン上にかかっています。修理する際には注意ください。警告当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。警告當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
Page 199 Appendix A: Warning Statements ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
Page 200 Appendix A: Warning Statements ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다. Waarschuwing Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.
Page 201 Appendix A: Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
Page 202 Appendix A: Warning Statements Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
Page 203 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
Page 204 ‫.قيرح وأ لطع يف ببستي دق ىرخأ تالوحمو تالباك يأ مادختسا .ميلسلا سباقلاو لصوملا مجح‬ ‫ لبق نم ةدمتعملا تالباكلا مادختسا تادعملاو ةيئابرهكلا ةزهجألل ةمالسلا نوناق رظحي‬UL ‫ وأ‬CSA ‫( ةمالع لمحت يتلاو‬UL/CSA) ‫ لبق نم ةددحملاو ةينعملا تاجتنملا ريغ ىرخأ تادعم يأ عم‬Supermicro.
Page 205 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...
Page 206 Appendix B: System Specifications Appendix B System Specifications Processors (per Node) Dual processors NVIDIA Grace™ CPU Superchip Embedded 480 GB ECC LPDDR5 with up to 1 TB/s throughput Note: Refer to the motherboard specifications pages on our website for updates to supported processors. Chipset (per Node) System on Chip (SoC) BIOS...
Page 207 Appendix B: System Specifications Regulatory Compliance FCC, ICES, CE, UKCA, VCCI, RCM, NRTL, CB Applied Directives, Standards EMC/EMI: 2014/30/EU (EMC Directive) Electromagnetic Compatibility Regulations 2016 FCC Part 15 Subpart B ICES-003 VCCI-CISPR 32 AS/NZS CISPR 32 BS/EN 55032 BS/EN 55035 CISPR 32 CISPR 35 BS/EN 61000-3-2...
Page 208 Appendix B: System Specifications General Data Center Environmental Specifications Particulate contamination specifications Air filtration: Data centers must be kept clean to Class 8 of ISO 14644-1 (ISO 2015). The air entering the data center should be filtered with a MERV 11 filter or better. The air within the data center should be continuously filtered with a MERV 8 filter or better.

Supermicro SuperServer ARS-121L-DNR-LCC User Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Supermicro SuperServer ARS-121L-DNR-LCC

Summary of Contents for Supermicro SuperServer ARS-121L-DNR-LCC
