HUAWEI NetEngine5000E Core Router
Configuration Guide - System Management
snmp-agent mib-view { excluded | included } view-name oid-tree
A MIB view is created, and manageable MIB objects are specified.
By default, an NM station has rights to access the objects in the Viewdefault view.
l excluded: If a few MIB objects on the device or some objects in the current MIB view do
l included: If a few MIB objects on the device or some objects in the current MIB view need
Step 7 Run:
snmp-agent community { read | write } { community-name | cipher community-name1 }
[ acl acl-number | mib-view view-name ]
The NM station's access rights are specified.
l read: NM station administrator configures the read parameter to provide read access to the
l write: NM station administrator configures the write parameter to provide read and write
l mib-view: If some of the NM stations that use the community name need to have rights to
l acl: If all the NM stations that use the community name need to manage specified objects on
Step 8 Run:
commit
The configuration is committed.
----End
Follow-up Procedure
After the access rights are configured, especially after the IP address of the NM station is
specified, if the IP address changes (for example, the NM station changes its location, or IP
addresses are reallocated due to network adjustment), you need to change the IP address of the
NM station in the ACL. Otherwise, the NM station cannot access the device.

3.3.3 (Optional) Configuring the Trap Function

This section describes how to specify the alarms to be sent to the NM station, which help you
to locate important problems. After relevant parameters are set, the security of alarm sending
can be improved.
Procedure
Step 1 Run:
system-view
Issue 01 (2011-10-15)
not or no longer need to be managed by the NM station, excluded needs to be specified in
the command to exclude these MIB objects.
to be managed by the NM station, included needs to be specified in the command to include
these MIB objects.
low level administrator for a specified view.
access to the low level administrator for a specified view.
access the objects in the Viewdefault view, mib-view view-name does not need to be
configured in the command.
the device, acl acl-number does not need to be configured in the command.
If some of the NM stations that use the community name need to manage specified objects
on the device, both mib-view and acl need to be configured in the command.
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
*
3 SNMP Configuration
69
