HUAWEI NetEngine5000E Core Router
Configuration Guide - System Management
l
l
Related Tasks
2.4 Configuring NTP Security Mechanisms

2.7.4 Example for Configuring Multicast Mode

In a multicast domain, the device with high clock precision functions as the NTP server, and
other devices are synchronized to the clock of the NTP server.
Networking Requirements
On a single NE5000E, an interface is numbered in the format of slot number/card number/
interface number. On an NE5000E cluster, the interface is numbered in the format of chassis
ID/slot number/card number/interface number. This requires the chassis ID to be specified along
with the slot number.
As shown in
Issue 01 (2011-10-15)
#
return
Configuration file of Router D
#
sysname RouterD
#
ntp-service authentication-keyid 16 authentication-mode md5 %@ENC;8HX
\#Q=^Q`MAF4<1!!
ntp-service reliable authentication-keyid 16
ntp-service authentication enable
#
interface GigabitEthernet1/0/0
undo shutdown
ip address 3.0.1.32 255.255.255.0
ntp-service broadcast-client
#
Return
Configuration file of Router F
#
sysname RouterF
#
interface GigabitEthernet1/0/0
undo shutdown
ip address 1.0.1.2 255.255.255.0
#
interface GigabitEthernet2/0/0
undo shutdown
ip address 3.0.1.2 255.255.255.0
#
ospf 1
area 0.0.0.0
network 1.0.1.0 0.0.0.255
network 3.0.1.0 0.0.0.255
#
return
CAUTION
Figure 2-7,
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
2 NTP Configuration
46
