List of events

B.2 List of events
Error code
Severity
(ID)
08065-0 ADM WARNING GNSS data
08067-0 ADM ERROR
0806A-0 ADM WARNING VMU connection
0806C-0 ADM ERROR
0806E-0 ADM ERROR
08078-0 ADM WARNING VMU TX frequency invalid
08104-0 ADM ERROR
08107-0 ADM ERROR
0810A-0 ADM ERROR
0810C-0 ADM ERROR
B-2
Description
PCB temperature
VMU frequency setup
VMU 10 MHz reference
Antenna communication
ADM FPGA load
ADM production data
File system integrity
Table B-1: Event messages
Appendix B: System messages
Explanation
Missing GPS data (fix).
ADM temperature too high. The ACU is not
equipped with a fan, so make sure there is
compliance with the environmental
specifications.
The ACU has lost connection with the sat
modem.
There is a mismatch in the frequency setup.
Probably the sat modem is not configured
correctly to match the requirements of the
ACU and antenna. A common mismatch is
the absence of Rx or Tx LO parameter in the
VSAT modem.
The VMU Rx or Tx reference signal is not
present. Whether this error Rx or Tx
reference, depends on the users selection
on the modem profile page. Make sure VMU
Rx/Tx cable is connected and that the VMU
is configured to output the RX/TX reference
signal.
VSAT modem unit provided a TX frequency
of zero. This may degrade tx performance.
To remove this warning re-configure the
modem to provide the correct tx frequency.
The ACU cannot communicate with the
antenna. Check cable and antenna.
The ADM FPGA cannot be initialised and
loaded.
Production data has been corrupted.
One or more file system partitions are
corrupt. You may have lost your settings
and collected statistics. If restarting the
system does not help, contact your service
partner.
98-144390-A
