To assemble the EXPLORER 3075GX

• Antenna positioner and electronics enclosure
• Feed assembly
• Transmit (Red, Tx) & Receive (Blue, Rx) RF cables
• BUC power cable (Gray)
• Power cable
• CD with user documentation
3.1.2

Initial inspection

Inspect the cases immediately upon receipt for evidence of damage during transport. If the
shipping material is severely damaged or water stained, request that the carrier's agent be
present when opening the cases. Save all packing material for future use.
After unpacking the system, inspect it thoroughly for hidden damage and loose
components or fittings. If the contents are incomplete, if there is mechanical damage or
defect, or if the system does not work properly, notify your dealer.
3.2 To assemble the EXPLORER 3075GX
3.2.1

Prerequisites

• When operating on uneven surfaces, use the rotating adjustment tube to move the feet
up and down to level the base and achieve stability.
Note
• The terminal may be anchored to the ground to meet operational requirements in high
wind conditions. For anchoring you may add extra weight to the support legs, or insert
stakes through holes on the support feet. The recommended weight values to hold the
terminal to the ground can be provided upon request.
• Do not cover the GNSS (GPS, Glonass, etc.) module.
• Do not cover the WLAN module.
3-2
WARNING! To avoid electric shock, do not apply power to the system
if there is any sign of shipping damage to any part of the front or rear
panel or the outer cover. Read the safety summary at the front of this
manual before installing or operating the system.
If the look angle is less than 12 degrees it is important to level the terminal.
Chapter 3: Assembly & start up 98-144390-A
