A.2

Product Dimensions

The dimensions shown below reflect the space needed to accommodate the full range of
motion in elevation and azimuth.
A.2.1

Side view

98-144390-A
30" / 76 cm
Figure A-1: EXPLORER 3075GX side view
Appendix A: Technical specifications
Product Dimensions
A-3
