Information fields on the Dashboard
DASHBOARD
System status
GPS position
Base orientation
Satellite profile
Satellite position
Azimuth
Elevation
RX RF frequency
Tuner signal strength
Tuner mode
Tracking RF frequency
Antenna TX allowed
Modem RX status
ACU part name, Antenna
part name, ACU serial
number, Antenna serial
number, Software
version
98-144390-A
Current status of the EXPLORER 3075GX
Examples:
Antenna software upload
Antenna POST (Power-On Self Test)
Ready (waiting for data from the modem or no satellite profile
selected)
Deployed idle (antenna ready)
Manual pointing
Acquisition ok (signal from the GX satellite acquired)
Safe mode (error, followed by an error description)
Current position, reported by the GNSS module
Orientation of the electronics enclosure.
Not used by this antenna.
Name of the currently active satellite profile.
Position of the satellite selected in Satellite profile.
Current value for azimuth.
Current value for elevation.
Ka band receiving frequency, auto-selected by modem
Current tuner signal strength
GSC (GX) or Narrowband
Current RF tracking frequency
Not allowed or Allowed
Not locked or Locked
Part names, serial numbers for antenna, software version of the
EXPLORER 3075GX.
Table 4-2: Web interface: DASHBOARD
