Navigation; Administration - COBHAM EXPLORER 3075GX Installation And User Manual

4.1.5

Navigation

On this page you can enter a fixed position or a fixed base heading. Do as follows:
1. Select SERVICE > Navigation from the left navigation pane.
2. Set the Position:
Item
Position mode GPS - GNSS module is used for current position (default).
3. Click Apply to save the new settings.
4.1.6

Administration

In this section of the web interface you can configure the following administrative settings:
• Access to the administration settings (user name, password)
• User permissions (guest login)
• Import and export of a system configuration
• Reset to factory default
Access to the administration settings (user name, password)
You can logon as an administrator or as guest (user name: guest, password: guest). The
Administration settings require an Administration user name and password. To log on as
administrator, do as follows:
1. Enter the IP address of the EXPLORER 3075GX.
2. Enter the Administration user name and password.
98-144390-A
Figure 4-7: Web interface: SERVICE > Navigation
Manual - enter values from other position source. (Accuracy should
be better than 50 m.)
Table 4-4: Web interface: SERVICE > Navigation
Chapter 4: Setup and operation
Setup using the web interface
Description
4-9
