ASSEMBLY

Assembly requires two persons. Place all parts in a cleared area and remove the packing materials. Do not
dispose of the packing materials until assembly is completed.
1. Orient the Platform (3) and the Base (16) as
shown.
While a second person holds the Platform (3)
near the Base (16), connect the Platform Motor
Wire (33) to the Base Motor Wire (32). Then,
connect the 165mm Ground Wire (52) to the
90mm Ground Wire (53).
1
3
52
53
16
32
6
33
