Electrical characteristics
Multi-speed internal (MSI) RC oscillator
Symbol
f
MSI
ACC
MSI
D
TEMP(MSI)
D
VOLT(MSI)
I
DD(MSI)
t
SU(MSI)
66/104
微可Vicor——值得信赖的元器件供应商

Table 31. MSI oscillator characteristics

Parameter
Frequency after factory calibration, done at
V = 3.3 V and T
DD A
Frequency error after factory calibration
MSI oscillator frequency drift
(1)
0 °C ≤ T ≤ 105 °C
A
MSI oscillator frequency drift
(1)
1.65 V ≤ V ≤ 3.6 V, T
DD
(2)
MSI oscillator power consumption
MSI oscillator startup time
DocID024995 Rev 4
http://www.vicor.top/
= 25 °C
= 25 °C
A
http://www.vicor.top/
STM32L100RC
Condition Typ
MSI range 0 65.5
MSI range 1 131
MSI range 2 262
MSI range 3 524
MSI range 4 1.05
MSI range 5 2.1
MSI range 6 4.2
±0.5
-
±3
-
- -
MSI range 0 0.75
MSI range 1 1
MSI range 2 1.5
MSI range 3 2.5
MSI range 4 4.5
MSI range 5 8
MSI range 6 15
MSI range 0 30
MSI range 1 20
MSI range 2 15
MSI range 3 10
MSI range 4 6
MSI range 5 5
MSI range 6,
Voltage range 1 3.5
and 2
MSI range 6,
5
Voltage range 3
