b. Lift the handle on the battery 2
c. Lift the battery out of the power supply unit 3 .
4. Install the replacement battery.
CAUTION:
The replacement battery has protective end caps that must be removed prior to use.
a. Remove the battery from the packaging.
b. Remove the end caps.
c. Attach the end caps to both ends of the battery that you removed and place the battery in the
original packaging.
d. Place the replacement battery in the opening on top of the power supply in its proper orientation.
e. Press the battery to seat the connector.
f. Place the handle in its downward location
5. Push the power supply unit back into the enclosure until the handle starts to move.
6. Finish inserting the power supply unit into the enclosure by closing the handle until the locking catch
clicks into place.
7. Reattach the power cable and cable retention bracket.
8. Turn on the power switch to the power supply unit.
If required, return the battery. Follow all packaging instructions, and use any packaging materials for
shipping that are supplied to you.

Releasing the cable retention bracket

This topic provides instructions for releasing the cable retention bracket when removing the power cords
from the power supply unit.
Be careful when you are replacing the hardware components that are located in the back of the system
that you do not inadvertently disturb or remove any cables that you are not instructed to remove.
Each cable retention bracket comes attached to the back of the power supply unit by the power cord
plug-in.
To release a cable retention bracket, perform these steps:
1. Unlock the cable retention bracket that is around the end of the power cord as shown in Figure 29 on
page 99.
