RIGOL
Trigger Offset
Trigger Holdoff range
Set Level to 50%
(Typical)
Edge Trigger
Edge trigger slope
Pulse Trigger
Trigger condition
Pulse Width range
Video Trigger
Video standard &
line frequency
Slope Trigger
Trigger condition
Time setting

Alternate Trigger

Trigger on CH1
Trigger on CH2
Pattern Trigger
Trigger mode
Duration Trigger
Trigger Type
Qualifier
Time setup
Measurements
Manual
Cursor
Track
Auto
Auto Measure Vpp, Vamp, Vmax, Vmin, Vtop, Vbase, Vavg, Vrms, Overshoot,
Preshoot, Freq, Period, Rise Time, Fall Time, +Width, -Width,
+Duty, -Duty, Delay1→2 , Delay1→2
Remarks:
[1] When sampling is 1GSa/s, only single channel can be used.
[2] For DS1000D series.
1-4
Normal mode: pre-trigger (storage depth/ 2*sampling
rate), delayed trigger 1s
Slow Scan mode: pre-trigger 6div, delayed trigger 6div
500ns~1.5s
Input signal frequency ≥50Hz
Rising, Falling, Rising + Falling
(＞, ＜, =) Positive pulse, (＞, ＜, =) negative pulse
20ns ~10s
Support standard NTSC, PAL and SECAM broadcast systems.
Line number range: 1~525 (NTSC) and 1~625 (PAL/SECAM)
(＞, ＜, =) Positive slope, (＞, ＜, =) negative slope
20ns~10s
Edge, Pulse, Video, Slope
Edge, Pulse, Video, Slope
[2]
D0~D15 select H, L, X,
[2]
D0~D15 select H, L, X
＞, ＜, =
20ns~10s
Voltage difference between cursors (∆V)
Time difference between cursors (∆T)
Reciprocal of ∆T in Hertz (1/∆T)
Voltage value for Y-axis waveform
Time value for X-axis waveform
Cursors are visible for Automatic Measurement
,
Service Guide for DS1000E, DS1000D Series
Chapter 1 Specifications
