Chapter 1 Specifications

General Specifications

Display
Display Type
Display Resolution
Display Color
Display Contrast (typical)
Backlight
Brightness(typical)
Probe Compensator Output
Output Voltage(typical)
Frequency(typical)
Power
Supply Voltage
Power Consumption
Fuse
Environmental
Ambient Temperature
Cooling Method
Humidity
Altitude
Mechanical
Size
Heavy
IP Protection
IP2X
Calibration Interval
The recommended calibration interval is one year
Service Guide for DS1000E, DS1000D Series
5.7 in. (145 mm) diagonal TFT Liquid Crystal Display
320 horizontal ×RGB×234 vertical pixels
64k color
150:1
300 nit
Approximately 3Vpp (peak to peak value)
1kHz
100 ~ 240 VAC
RMS
Less than 50W
2A, T rating, 250 V
Operating 10℃~ 40℃
Non-operating -20℃~ +60℃
Fan force air flow
+35℃ or below: ≤90% relative humidity
+35℃~ +40℃: ≤60% relative humidity
Operating 3,000 m or below
Non-operating 15,000 m or below
Width
Height
Depth
Without package
Packaged
, 45~440Hz, CAT II
303mm
154mm
133 mm
2.3 kg
3.5 kg
RIGOL
1-5
